Fisher 75B0018X012 Packing Box Spare Component

Technical Specifications

Model：75B0018X012 Brand：Fisher Product Type: Control valve packing box spare component

Module Feature

Fisher 75B0018X012 is precision alloy packing box component for Fisher globe control valve. It is the housing for valve stem packing set. It adopts high strength stainless steel with anti-corrosion performance. It holds packing rings to prevent process medium leakage along valve stem. Widely used in oil,gas,chemical and power plant globe control valves.

Working principle: Accommodate stem packing and reduce stem leakage Onboard components: Alloy packing box body, locating pins, sealing washer

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, dimensional measurement, surface corrosion inspection, packing assembly fit test

Programming software

No dedicated software required

Mechanical & Structure

Mounting: Installed on valve bonnet upper section Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +425℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher control valve packing spare part

System compatibility

Compatible with matched Fisher globe control valve and pneumatic diaphragm actuator for industrial process control system.

Function

75B0018X012 is packing box component manufactured by Fisher. It contains packing rings and provides radial compression for valve stem sealing. It restricts fugitive emission leakage along valve stem. It maintains stem alignment and reduces packing wear during valve stroke movement. It is key spare part for valve stem sealing overhaul.

Installation

Follow lockout/tagout safety procedure before installation. Isolate pipeline and release process pressure. Disassemble valve bonnet, replace old packing box component. Install packing rings in sequence and check stem clearance. Reassemble valve and perform hydrostatic test and fugitive emission leakage inspection.

Interface

Valve bonnet mounting structure, locating pin holes, no LED indicators on 75B0018X012.

Diagnostic

Stem external leakage: Packing box deformation or packing damage. Valve stem sticking: Packing box misalignment and stem friction abnormal. Fugitive emission exceed: Corrosion or scratch on packing box inner bore.

Product Brief

75B0018X012 Fisher globe control valve alloy packing box component,used for industrial process valve stem packing assembly replacement and fugitive emission control,valve bonnet spare part.
