Fireye UVM-3 UV Flame Scanner

Technical Specifications

Model：UVM-3 Brand：Fireye Product Type: Self-checking ultraviolet flame scanner for industrial burner flame detection

Detection Feature:

• Detection spectrum: Ultraviolet UV band

• Self-check function: Built-in automatic UV tube health diagnostic

• Flame target: Gas, light oil industrial burner flame

• Operating principle: Detect UV flicker signal generated by combustion flame

• Response characteristic: Fast flame loss response

Electrical Parameters:

• Supply voltage: Powered by Fireye burner chassis

• Output: UV flame signal to UV self-check amplifier chassis

• Cable type: Fireye specified shielded cable

• Max cable length: Subject to system wiring specification

Mechanical & Structure:

• Housing: Compact metal housing

• Mounting: Burner sight pipe mount

• Window: UV transparent quartz window

• Thread interface: Standard burner observation port thread

Environmental:

• Operating temperature: -40℃ ~ +85℃

• Ambient humidity: 0~90% non-condensing

• Certification: UL, FM approved

• Weight: Approx 0.3kg

System compatibility

UVM-3 belongs to Fireye UV flame scanner family. Compatible with Fireye ZB110UVSC, ZB230UVSC, YB110UVSC, YB230UVSC burner control chassis. Matches YP series programmer modules, BLV512 / BLL510 display units. Widely used for gas and light oil boiler and furnace burners. Widely used for combustion safety system spare replacement.

Function

UVM-3 is self-checking ultraviolet flame scanner manufactured by Fireye. It senses ultraviolet radiation from combustion flame and converts flame flicker signal to electrical signal and transmits to burner control chassis. The integrated self-check circuit continuously tests UV sensor health during operation, to prevent false flame indication caused by UV tube aging or failure. When flame extinguishes, the scanner stops sending flame signal, the burner chassis will initiate safety lockout and cut fuel supply to avoid explosion hazard. Widely deployed for industrial boiler and furnace burner flame monitoring and spare replacement.

Installation

Follow lockout/tagout safety procedure before installation. Mount UVM-3 on burner sight port, ensure proper optical alignment towards flame. Clean quartz window before commissioning. Run shielded cable between scanner and BurnerLogix UV self-check chassis, strictly follow Fireye wiring schematic. Power on, test scanner self-check function, verify flame signal value during burner light-off.

InterfaceQuartz viewing window,metal mounting thread,2-core signal terminal,metal enclosure for Fireye UVM-3.

FeatureOriginal Fireye UVM-3 self-check UV flame scanner,built-in sensor health diagnosis,UV flame detection,compact sight pipe mounting,UL & FM safety certified. This spare unit is used for industrial boiler burner flame detection maintenance and hardware replacement.

DiagnosticNo flame signal: Inspect quartz window contamination, optical alignment, scanner cable continuity. Self-check fault: Verify scanner model match, check UV tube aging and wiring connection. Intermittent flame signal: Check vibration, loose wiring or soot accumulation on window. False flame indication: Confirm no UV interference source nearby burner.

Product BriefUVM-3 is Fireye self-check UV flame scanner, it detects gas/light oil flame and performs continuous sensor self-test, works with BurnerLogix UV self-check chassis,classic spare for industrial furnace combustion control system.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
