Fireye TS752-2 Temperature Sensor

Technical Specifications

Model：TS752-2 Brand：Fireye Product Type: Immersion temperature transmitter for industrial boiler and combustion system temperature measurement

Detection Feature:

• Sensing element: Platinum positive temperature coefficient element

• Temperature measuring range: 32℉ ~ 752℉ (0℃ ~ 400℃)

• Signal output: 4-20mA, linear proportional to measured temperature

• Insertion length: 2 inch (50.8mm)

• Application target: Boiler water temperature, flue gas stack temperature, process fluid temperature

Electrical Parameters:

• Signal type: Analog 4~20mA current loop

• Wiring: Two-wire connection

• No on-site calibration required after factory setting

• Compatible control system: Fireye BurnerLogix, Nexus PPC4000 fuel-air ratio controller

Mechanical & Structure:

• Mount thread: 1/2" -14 NPT

• Protective sleeve: Integrated stainless steel thermowell

• Housing: IP rated metal terminal head

• Probe structure: Straight short immersion probe design

Environmental:

• Operating temperature: Probe up to 400℃

• Ambient humidity:0~85% non-condensing

• Certification: UL, FM approved

• Weight: Approx 1.1kg

System compatibilityTS752-2 belongs to Fireye TS752 series temperature sensor family. Compatible with Fireye BurnerLogix burner management system and Nexus PPC4000 fuel-air ratio controller. Suitable for gas and light oil boiler and furnace burners. Widely used for combustion safety system spare replacement.

FunctionTS752-2 is immersion temperature transmitter manufactured by Fireye. Platinum sensing element detects medium temperature and converts temperature value into standard 4-20mA linear analog signal and transmits to matched combustion controller. Stainless steel thermowell protects sensing probe from high temperature, soot and medium corrosion. Factory pre-calibrated, no field adjustment required. It monitors boiler water temperature or stack exhaust temperature for combustion optimization and over-temperature protection. Short 2-inch probe is ideal for shallow mounting ports. Widely deployed for industrial boiler and furnace flame continuous monitoring and spare replacement.

InstallationFollow lockout/tagout safety procedure before installation. Mount TS752-2 onto vessel or flue tapping port via 1/2" NPT thread. Insert the 2-inch probe into medium or flue gas flow. Run two-core shielded cable to PPC4000 / BurnerLogix controller, strictly follow Fireye wiring schematic. Power on and verify 4-20mA signal reading during burner commissioning.

InterfacePlatinum sensing tip,stainless steel thermowell,1/2"NPT mounting thread,two-wire signal terminal box,metal terminal housing for Fireye TS752-2.

FeatureOriginal Fireye TS752-2 immersion temperature transmitter,2 inch short insertion probe,0~400℃ range,4-20mA linear output,stainless steel thermowell,UL & FM safety certified. This spare unit is used for industrial boiler burner temperature detection maintenance and hardware replacement,ideal for shallow installation ports.

DiagnosticAbnormal 4-20mA signal: Inspect probe corrosion, thermowell fouling, cable continuity and terminal connection. Fixed value signal: Check probe burnout or circuit damage. Signal drift: Verify installation position, mechanical vibration and ambient thermal interference. No output signal: Inspect power supply and two-wire loop wiring.

Product BriefTS752-2 is Fireye immersion temperature sensor with 2 inch short probe,0~400℃ range and 4-20mA output,works with BurnerLogix and PPC4000 combustion controllers,classic spare for industrial furnace combustion control system.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
