Extreme Networks VSP 4900-12MXU-12XE Hybrid Access & Aggregation Switch

Technical Specifications

Model：VSP-4900-12MXU-12XE Brand：Extreme Networks Product Type: 1U rack mount Layer2/L3 hybrid PoE+ aggregation switch (VSP4000 family)

Front Ports:

• 12 × 10/100/1000BASE-T RJ45 ports, IEEE802.3at PoE+, max 30W per port

• 12 × 1/10G SFP+ high-speed fiber uplink slots for optical transceivers or DAC/AOC cables

• RJ45 serial console port

• USB port for firmware upgrade

• LED indicators for port link, activity, power and fault alarm

Rear Panel Interfaces:

• 1 × OOB 10/100/1000BASE-T out-of-band management port

• Dual hot-swappable AC PSU slots, redundant power optional

• Hot-swappable fan tray

• Equipment grounding terminal

Switching & Layer Features: Switch Fabric: 240 Gbps full duplex Forwarding Rate: 180 Mpps MAC Address Table: 128K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN Routing: IPv4 / IPv6 static & dynamic routing Security: 802.1X, ACL, storm control, hardware MACsec QoS: Hardware L2-L4 classification, 8 priority queues Stacking: VOSS fabric stacking support OS: VOSS operating system Virtualization: VRF, virtual switch instance

Power & Mechanical: Power Supply: Dual hot-swappable AC power modules PoE Total Budget: Max 720W PoE+ power capacity Cooling: Hot-swappable fan tray Operating temperature：0℃ ~ +40℃ Dimension: 442mm × 44mm × 420mm Weight: Approx 7.8 kg Mounting: Standard 19-inch 1U rack bracket

System compatibility

VSP-4900-12MXU-12XE belongs to Extreme VSP4000 virtual services platform family. Compatible with Extreme certified SFP / SFP+ transceivers, DAC and AOC cables. Supports VOSS fabric stacking with other VSP4000 series switches. Designed for campus building aggregation, hybrid PoE access and fiber uplink convergence. Widely used for Wi-Fi AP, IP camera and IP phone network spare replacement.

Function

VSP-4900-12MXU-12XE is hybrid PoE+ aggregation switch manufactured by Extreme Networks. It supplies power and data via 12 PoE+ copper ports for wireless AP, IP cameras and VoIP phones. 12×10G SFP+ ports provide high-density 10G fiber interfaces for uplink or remote fiber access. VOSS OS delivers advanced layer3 routing, VRF and fabric virtualization capability. Hot-swappable fan and PSU support online maintenance, minimizing network outage risk. Widely deployed for large campus, smart building and industrial hybrid copper/fiber aggregation network spare replacement.

Installation

Follow ESD protection procedure. Mount switch into standard 19-inch rack. Install hot-swappable AC PSU and fan tray. Insert SFP/SFP+ transceivers or DAC/AOC cables. Connect Cat5e/Cat6 cables to PoE terminals. Access serial console port for VOSS initial configuration, set VLAN, PoE allocation, stacking and QoS policy. Verify port link and PoE power status after power-up.

Interface

12×PoE+ RJ45 ports,12×10G SFP+ slots,USB port,serial console port,OOB management port,dual hot-swap PSU slots,hot-swap fan tray,status LED indicators for Extreme Networks VSP-4900-12MXU-12XE.

Feature

Original Extreme Networks VSP-4900-12MXU-12XE hybrid aggregation switch,1U,12×1G PoE+ +12×10G SFP+,hardware MACsec,VOSS fabric stacking,VOSS OS,hot swappable redundant power and fan. This spare unit is used for enterprise campus hybrid PoE and fiber aggregation network maintenance and hardware replacement.

Diagnostic

Switch boot failure: Check AC power input and PSU installation. PoE port no power: Verify total PoE budget, power allocation and PD compatibility. SFP+ port link down: Check transceiver compatibility, optical power and fiber connector cleanliness. Fabric stack split fault: Confirm stacking cable and match VOSS firmware version. Temperature alarm: Inspect fan tray running status and rack air circulation.

Product BriefVSP-4900-12MXU-12XE is Extreme Networks VSP4000 series 1U hybrid PoE+ aggregation switch with 12 PoE+ copper ports and 12×10G SFP+ ports, VOSS fabric stacking,classic spare for enterprise mixed fiber-copper campus aggregation network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
