Extreme Networks SOT2206-0112 S-Series 10G SFP+ Option Module

Technical Specifications

Model：SOT2206-0112 Brand：Extreme Networks Product Type: Hot-swappable optional I/O line card for S-Series modular chassis, S140 class module

Front Ports:

• 12 × 1G/10G SFP+ multi-speed slots, support optical transceivers, DAC/AOC cables

• LED indicators for port link, activity, module status and fault alarm

Backplane Interface:

• High-speed backplane connector to connect S-Series chassis fabric

• Hot swap capable, online replacement without chassis power off

• Works with S-Series chassis supervisor to forward traffic

Switching & Software Features:

• OS: EOS operating system

• Minimum supported firmware: 07.72.01.0021, recommended 08.62.04.0001

• MAC Address Table: 128K entries

• Max Jumbo Frame: 9216 bytes

• VLAN: Up to 4094 802.1Q tagged VLAN

• Routing: IPv4 / IPv6 static & dynamic routing

• Security: 802.1X, ACL, storm control

• QoS: Hardware L2-L4 classification, multiple priority queues

Power & Mechanical:

• Power supplied via chassis backplane

• Cooling relies on chassis fan tray airflow

• Operating temperature：0℃ ~ +40℃

• Standard S-Series line card form factor

• Weight: Approx 1.4kg

System compatibility

SOT2206-0112 belongs to Extreme S-Series S140 class line card family. It is compatible with S-Series modular chassis platform. Matches with S-Series supervisor modules and other S140 class I/O cards. Compatible with Extreme SFP+ optical transceivers, DAC and AOC cables. Widely used for S-series chassis 10G port expansion and spare replacement.

Function

SOT2206-0112 is optional 12-port 10G SFP+ line card for Extreme S-Series modular chassis. It expands chassis port density, providing 12 multi-speed SFP+ interfaces for fiber uplink or server access. Hot-swap design allows engineers replace the module online without powering down whole chassis. It works with chassis supervisor card to handle data forwarding, VLAN segmentation and routing services. Widely deployed for enterprise campus core and data center modular chassis port expansion spare replacement.

Installation

Follow ESD protection procedure. Insert SOT2206-0112 module into empty chassis slot and fasten locking screws. Chassis power remains on for hot swap. Wait for module initialization. Access chassis CLI to verify module online status, check port LEDs and upgrade firmware if version mismatch. Configure port VLAN and routing policy as requirement.

Interface

12×SFP+ slots,status LED indicators,high-speed chassis backplane connector for Extreme Networks SOT2206-0112.

Feature

Original Extreme Networks SOT2206-0112 S-Series S140 class line card,12×10G multi-speed SFP+ ports,hot swappable,EOS system compatible. This spare unit is used for S-Series modular chassis port expansion and core network hardware maintenance.

Diagnostic

Module unrecognized: Confirm module fully seated and locking screws tightened. Port link down: Verify SFP+ transceiver compatibility, fiber cable and connector cleanliness. Firmware incompatibility: Upgrade chassis EOS firmware to recommended version. Module fault alarm: Check chassis fan operation and environmental temperature. Port cannot enable: Validate license and slot configuration on chassis supervisor.

Product BriefSOT2206-0112 is Extreme Networks S-Series S140 class hot-swappable 12×10G SFP+ option line card for modular chassis,classic spare for core chassis port expansion.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
