Extreme Networks SL8013-1206-F8 S-Series S180 40G QSFP+ Fabric I/O Line Card

Technical Specifications

Model：SL8013-1206-F8 Brand：Extreme Networks Product Type: Hot-swappable S180 class fabric I/O line card for S-Series modular chassis

Front Ports:

• 6 × 40G QSFP+ slots, support 40GBASE-SR4/LR4 transceivers, QSFP+ DAC/AOC cables

• Each 40G port supports breakout to 4×10G SFP+

• LED indicators for port link status, activity, module health and fault alarm

Backplane Interface:

• High-speed backplane connector connecting to S-Series chassis fabric

• Hot swap support, online replacement without chassis power shutdown

• Works cooperatively with S-series supervisor module for fabric traffic forwarding

Switching & Software Features:

• OS: EOS operating system

• Minimum supported firmware: 08.11.01.0014, recommended version 08.62.04.0001

• MAC Address Table: 128K entries

• Max Jumbo Frame: 9216 bytes

• VLAN: Up to 4094 802.1Q tagged VLAN

• Routing: IPv4 / IPv6 static & dynamic routing protocols

• Security: 802.1X, ACL, broadcast storm control

• QoS: Hardware L2-L4 traffic classification, multiple priority queues

Power & Mechanical:

• Power supply: Powered through chassis backplane

• Cooling: Dependent on chassis fan tray airflow

• Operating temperature：0℃ ~ +40℃

• Standard S-Series S180 line card form factor

• Weight: Approx 1.48kg

System compatibility

SL8013-1206-F8 belongs to Extreme S-Series S180 class fabric line card family. Compatible with S4, S6, S8 S-Series modular chassis platform, matching S-series supervisor modules and other S180/S140 I/O cards. Compatible with Extreme certified QSFP+ 40G optical transceivers, DAC and AOC cables. Widely applied in core chassis fabric interconnection and spare replacement for campus and data center core network.

Function

SL8013-1206-F8 is a 6-port 40G QSFP+ fabric line card for Extreme S-Series modular chassis. It provides high-bandwidth 40G fabric interfaces for inter-chassis or spine uplink connection. Each QSFP+ port supports breakout function to four independent 10G ports, flexible for mixed 10G/40G deployment. Hot-swap design allows engineers to replace the module online without cutting power of the whole chassis. It collaborates with chassis supervisor for high-speed fabric forwarding, VLAN segmentation and routing processing. Widely deployed for enterprise campus core and data center modular chassis fabric expansion spare replacement.

Installation

Follow ESD protection procedure. Insert SL8013-1206-F8 module into empty chassis slot and fasten locking screws. Hot swap operation can be performed with chassis powered on. Wait for module initialization. Access chassis CLI to verify module online status, check port LEDs and upgrade firmware if version mismatch. Insert QSFP+ transceivers and fiber cables, configure port breakout, VLAN and routing policy according to site requirements.

Interface

6×QSFP+ slots,status LED indicators,high-speed chassis backplane connector for Extreme Networks SL8013-1206-F8.

Feature

Original Extreme Networks SL8013-1206-F8 S-Series S180 class fabric line card,6×40G QSFP+ ports,port breakout to 4×10G,hot swappable,EOS system compatible. This spare unit is used for S-Series modular chassis high-speed fabric expansion and core network hardware maintenance.

Diagnostic

Module undetected: Confirm module fully seated and locking screws tightened. Port link down: Verify QSFP+ transceiver compatibility, fiber cable integrity and connector cleanliness. Firmware incompatibility: Upgrade chassis EOS firmware to minimum required version 08.11.01.0014 or newer. Module fault alarm: Check chassis fan tray working status and ambient operating temperature. Port breakout failure: Verify EOS license and correct port breakout configuration on supervisor.

Product BriefSL8013-1206-F8 is Extreme Networks S-Series S180 class hot-swappable 6×40G QSFP+ fabric line card for S4/S6/S8 modular chassis,classic spare for core chassis high-speed fabric interconnection.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
