Extreme Networks 6E233-49 SmartSwitch 6000 Interface Module

Technical SpecificationsModel:6E233-49 Brand:Extreme Networks Product Type:Hot-swappable chassis Ethernet I/O module Compatible chassis:SmartSwitch 6000 model 6C105 Ports:48×10BASE-T ports via four RJ21 connectors Uplink:1 slot for optional HSIM high-speed interface module Port speed:10 Mbps per port VLAN:802.1Q VLAN support Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:2.0 kg

System compatibility6E233-49 is the legacy 10Mbps Ethernet module for Cabletron SmartSwitch 6000 6C105 chassis. It uses RJ21 telco connectors for 48-port breakout to 10BASE-T end devices. HSIM uplink module can be installed for fast ethernet, gigabit, FDDI or ATM uplink. Widely used for very old enterprise network maintenance spare replacement.

Function6E233-49 provides 48×10Mbps switched Ethernet ports for legacy building access networks. It supports VLAN segmentation, traffic prioritization and protocol-based filtering. It reports port status, module temperature and power consumption to chassis management. Used to replace aged 10M I/O blades for SmartSwitch 6000 chassis overhaul.

InstallationHot-swappable replacement. Insert 6E233-49 into empty slot of 6C105 chassis. Tighten captive screws. Connect RJ21 telco cables to breakout panels. Install HSIM uplink module if required. Verify module online status and port connectivity before putting into production.

InterfaceFour RJ21 telco connectors, one HSIM slot, module status LEDs, ejector handles for Cabletron 6E233-49.

FeatureOriginal Cabletron SmartSwitch 6000 48-port 10BASE-T module, hot-swappable, VLAN capable, flexible uplink via HSIM card, built-in self-diagnostic function. This spare supports maintenance of legacy 10Mbps enterprise access networks.

DiagnosticModule not detected: check blade seating, captive screws and backplane contact. Port no link: verify RJ21 cable and breakout wiring. HSIM uplink failure: check HSIM installation and firmware compatibility. Over-temperature alarm: check chassis fan tray operation and dust removal.

Product Brief6E233-49 is Cabletron hot-swappable 48-port 10BASE-T interface module for SmartSwitch 6000 6C105 chassis, classic spare part for legacy enterprise 10Mbps access network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
