Extreme Networks 4050-00015 SFP Optical Transceiver

Technical SpecificationsModel: 4050-00015 Brand: Extreme Networks Product Type: Hot-swappable SFP Gigabit Optical Transceiver Mounting: Plug into SFP port of Extreme switch Operating temperature: 0℃ ~ +70℃ Storage temperature: -40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Standard:1000BASE-SX Wavelength: 850nm Fiber type: OM1/OM2 multimode fiber Max distance: 550 meters Connector: LC duplex Digital monitoring: DDM / DOM Weight:0.03 kg

System compatibility4050-00015 is Extreme Networks original SFP 1G SX optical transceiver. Compatible with Extreme Summit X440, X460, X620, VSP and other series switches with SFP slots. Widely used for enterprise campus access layer gigabit fiber uplink, network maintenance and spare replacement.

Function4050-00015 converts gigabit electrical signal into optical signal for transmission over multimode fiber. It supports DDM to monitor real-time optical transmit power, receive power, module temperature and supply voltage. It triggers alarm once optical signal loss, over-temperature or module hardware fault occurs. It is used to replace faulty SFP modules for gigabit fiber links in enterprise LAN.

InstallationPower off before installation. Insert SFP transceiver into the switch SFP slot. Connect LC duplex multimode fiber cable to module port. Verify module identification by switch OS, check optical power and link status before putting into production.

InterfaceSFP edge connector, LC duplex fiber port, DDM digital diagnostic interface for Extreme Networks 4050-00015 optical transceiver.

FeatureOriginal Extreme Networks 1000BASE-SX SFP module, hot-swappable, 850nm short wavelength, DDM real-time monitoring, low power consumption, compliant with IEEE802.3z standard. This spare supports enterprise campus gigabit fiber network maintenance.

DiagnosticModule undetected: check insertion, slot status and switch firmware compatibility. Port link down: verify LC fiber cable, fiber type, optical power and port administrative status. Low optical power alarm: check fiber end-face contamination, connector damage and excessive cable bending.

Product Brief4050-00015 is Extreme Networks 1000BASE-SX SFP multimode optical transceiver. It provides short-distance gigabit fiber transmission for enterprise access switches, classic spare part for legacy campus network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
