Extreme Networks 16419-16117 SFP+ Optical Transceiver

Technical SpecificationsModel:16419-16117 Brand: Extreme Networks Product Type: Hot-swappable SFP+ 10G Optical Transceiver Mounting: Plug into SFP+ port of Extreme switch Operating temperature:0℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Standard:10GBASE-LR Wavelength:1310nm Fiber type: OS2 single-mode fiber(SMF) Max distance:10 kilometers Connector: LC duplex Digital monitoring: DDM / DOM Weight:0.04 kg

System compatibility16419-16117 is Extreme Networks original SFP+ 10G LR optical transceiver. Compatible with Extreme Summit X440-G2, X460-G2, X620, X650, X670, VSP series switches equipped with SFP+ slots. Widely used for enterprise campus and metropolitan long-distance 10G fiber uplink, network maintenance and spare replacement.

Function16419-16117 converts 10G electrical signal into optical signal for transmission over single-mode fiber. It supports DDM to monitor transmit optical power, receive power, module temperature and supply voltage. It triggers alarm once optical signal loss, over-temperature or module hardware fault occurs. It is used to replace faulty SFP+ modules for long-distance 10G fiber links.

InstallationPower off before installation. Insert SFP+ transceiver into the switch SFP+ slot. Connect LC duplex single-mode fiber cable to module port. Verify module identification by switch OS, check optical power and link status before putting into production.

InterfaceSFP+ edge connector, LC duplex fiber port, DDM digital diagnostic interface for Extreme Networks 16419-16117 optical transceiver.

FeatureOriginal Extreme Networks 10GBASE-LR SFP+ module, hot-swappable,1310nm long wavelength, DDM real-time monitoring, low power consumption, compliant with IEEE802.3ae standard. This spare supports enterprise and data center long-reach 10G fiber network maintenance.

DiagnosticModule undetected: check insertion, slot status and switch firmware compatibility. Port link down: verify LC fiber cable, single-mode fiber type, optical power and port administrative status. Low optical power alarm: check fiber end-face contamination, connector damage and excessive cable bending.

Product Brief16419-16117 is Extreme Networks SFP+ 10GBASE-LR single-mode optical transceiver. It provides long-distance 10G fiber transmission for enterprise aggregation and core switches, classic spare part for long haul 10G network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
