Eaton IZMAG065D010SA00000 Trip Unit Module Unit

Module Feature

IZMAG065D010SA00000 belongs to Eaton Moeller IZMX series electronic trip unit for air circuit breaker. Rated 650A,model IZMAG065D010SA00000. It provides adjustable long-time overload,short-time delay and instantaneous short-circuit protection. Integrated current measurement and fault logging function. Designed to match IZMX withdrawable air circuit breaker for main power distribution protection in industrial plant and data center.

Working principle

Current transformer samples line current and sends signal to electronic trip unit. Microprocessor compares measured current with preset threshold. It triggers breaker tripping for overload,short-circuit or earth fault. It stores fault record for post-fault diagnosis.

Onboard components

Current sensing interface,MCU control board,parameter setting dip switch / digital interface,memory chip,trip output relay,status LED.

LED indicators

Power LED,pre-alarm LED,fault trip LED.

Hardware self-diagnosis

Power supply check,CT signal integrity,self-test,over temperature detection,memory data verification.

Programming software

Eaton PowerManager software,supports trip parameter configuration,fault history readout and breaker monitoring.

Electrical & Process Parameters

Model:IZMAG065D010SA00000 Brand:Eaton Device type:IZMX Series Electronic Trip Unit Rated current:650A Trip function:Long time overload,short time delay,instantaneous short circuit Communication:Optional bus communication Power supply:Self-powered from line current Cooling:Natural convection cooling Protection:Overload,short circuit,ground fault protection for main ACB

Mechanical & Structure

Mounting:Installed inside IZMX air circuit breaker Protection class:IP20 when assembled Housing:Flame retardant plastic housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: Eaton Moeller original electronic trip unit for IZMX air circuit breaker

Installation

Follow strict ESD safety procedure before handling.Mount trip unit into IZMX breaker body. Connect CT wiring and trip output. Set protection parameters and perform function test before commissioning.

Interface

CT signal terminal,trip coil drive terminal,optional communication port.

Diagnostic

No trip signal:CT wiring loose or trip unit power loss. False trip:incorrect protection setting or electrical noise interference. Fail to record fault:internal memory failure.

Product Brief

Eaton IZMAG065D010SA00000 IZMX series 650A electronic trip unit,provides adjustable overload and short-circuit protection,matched with IZMX air circuit breaker for industrial low voltage main power distribution.
