Eaton Cutler-Hammer KPRL4KDT Circuit Breaker Twin Mount Kit Unit

Module Feature

KPRL4KDT belongs to Eaton Cutler-Hammer PRL4 panel accessory series. It is a complete twin mount connection hardware kit designed for K-frame circuit breakers (DK, KD, KDB, HKD, KDC). Rated 400A, 600VAC, three-phase application. Package includes copper bus connectors, mounting brackets, insulating deadfront cover, fastening hardware and installation instructions. This kit allows two K-frame breakers to be installed side-by-side inside PRL4 panelboard for power distribution branch circuits. Widely used for industrial and commercial building electrical panel retrofitting and new cabinet assembly.

Working principle

The copper connectors establish electrical connection between panel main bus and twin breakers. Metal brackets provide mechanical support and positioning, insulating deadfront cover prevents accidental contact with live conductive parts. It realizes mechanical fixing and power distribution connection for dual breakers in one panel compartment. No electronic components.

Onboard components

Copper connecting lugs/bus bars, galvanized steel mounting brackets, plastic insulating deadfront cover, bolts, washers, screws and installation manual.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Visual inspection of copper surface oxidation, check bracket deformation, verify insulation cover integrity, measure connection torque of fasteners.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:KPRL4KDT Brand:Eaton Cutler-Hammer Device type:PRL4 Panelboard Twin Mount Connection Kit Rated current:400A Rated voltage:600VAC Phase:3-phase Compatible breaker:K-frame DK,KD,KDB,HKD,KDC MCCB Cooling:Natural convection cooling Protection:Insulating deadfront cover for touch safety protection

Mechanical & Structure

Mounting:Panelboard internal mounting Protection class:IP20 after full assembly Housing:Copper conductor + steel bracket + plastic insulating cover

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:UL67 compliant Status: Eaton Cutler-Hammer original twin breaker mounting hardware accessory for PRL4 panelboard

Installation

Follow strict high voltage safety procedure before handling.Install brackets inside PRL4 panel, mount twin breakers and connect copper conductors.Torque all electrical connection bolts to specified value, fit deadfront cover before power energizing.

Interface

Panel main bus interface, breaker terminal connection interface, mounting hole interface.

Diagnostic

Copper connector overheating: insufficient bolt torque or poor contact surface. Insulation cover cracked: risk of accidental contact with live parts. Bracket deformed: causes breaker misalignment and vibration.

Product Brief

Eaton Cutler-Hammer KPRL4KDT 400A 600V twin mount connection kit, for installing two K-frame molded case breakers in PRL4 series panelboard, includes copper connectors, brackets and deadfront cover.
