DELEM DA-24e CNC Press Brake Controller

Technical Specifications

Model: DA-24e Brand: DELEM (Netherlands) Product Type: CNC Press Brake Controller Mounting: Panel mounting on bending machine cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 (front panel) Power supply: 24V DC Weight: 4.2 kg

System compatibility

DA-24e is an economical entry-level CNC controller for hydraulic press brake. It connects with DELEM DM series axis modules via HSB bus, compatible with torsion bar press brake and basic electro-hydraulic synchronous bending machines, widely used for old bending machine renovation and spare replacement in sheet metal workshops.

Function

DA-24e works as the core numerical operation control unit of hydraulic press brake. It supports numerical position programming, stores bending programs, tool library and material data. It supports up to 3 axes control including Y1,Y2,X, equipped with basic crowning compensation function. It monitors ram position and machine limit signals, triggers alarm when over-travel or signal failure occurs. It is used to replace defective controllers when the press brake cannot complete normal numerical bending programming.

Installation

Cut off main power supply before installation. Reserve panel cutout on machine cabinet, mount DA-24e and lock fasteners. Connect 24V DC power, HSB bus cable, encoder wires and digital I/O terminals. Verify wiring definition, upload machine parameters, run axis homing and trial bending before formal production.

Interface

RS232 communication port, encoder input ports, digital I/O terminals, analog valve output, LED status indicators for DELEM DA-24e controller.

Feature

Original DELEM economical CNC controller, monochrome LCD display, membrane keyboard, simple numerical programming, power-off program memory, built-in self-diagnostic function, low power consumption. This legacy spare part supports field repair of old DELEM hydraulic press brake systems.

Diagnostic

No display after power on: check 24V DC power supply and power fuse for DA-24e. Axis positioning deviation: verify encoder wiring polarity and machine parameter setting. HSB bus communication error: inspect bus cable connection, shielding and grounding condition.

Product Brief

DA-24e is Dutch DELEM economical CNC controller for hydraulic press brake. It executes numerical programming and 3-axis closed-loop control for sheet metal bending, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
