DELEM 7389-006/-2 Linear Encoder Feedback Cable

Technical Specifications

Model: 7389-006/-2 Brand: DELEM (Netherlands) Product Type: Linear encoder feedback signal cable Mounting: Wiring inside press brake electrical cabinet and machine arm Operating temperature: 0℃ ~ +70℃ Storage temperature: -20℃ ~ +80℃ Relative humidity: 5%~95%, non-condensing Protection: Full copper shielded, anti-electromagnetic interference Weight: 0.22 kg

System compatibility

7389-006/-2 is dedicated encoder feedback cable for DELEM Modusys system. It connects linear encoder and DM series axis control module, compatible with DA52,DA53,DA56,DA61,DA65 controllers and DM51 modules, widely used for electro-hydraulic synchronous press brake maintenance and spare replacement.

Function

7389-006/-2 transmits high-resolution position feedback signal from linear encoder to DM axis module. It delivers real-time ram position data to calculate axis deviation, guarantee Y1/Y2 axis synchronization accuracy during bending. The shielding layer suppresses interference generated by hydraulic valves and power circuits. It is used to replace damaged signal cable when the system reports encoder fault, position jumping or axis sync deviation.

Installation

Cut off main power supply before wiring. Route this signal cable separately from high-power power cables, avoid parallel laying with hydraulic valve power lines. Connect both ends to encoder and DM module terminals, properly ground the shielding layer. Fix cable with cable clips to prevent pulling during swing arm movement. Power on and perform encoder signal test before formal production.

Interface

Dedicated multi-pin connectors at both ends, twisted pair multi-core wire, full copper shield screen for DELEM 7389-006/-2 cable.

Feature

Original DELEM encoder signal cable, twisted pair structure, high density shielding, oil-resistant and wear-resistant outer jacket, stable transmission of high resolution position signal, strong anti-interference for harsh industrial environment. This legacy spare part supports field repair of DELEM electro-hydraulic press brake systems.

Diagnostic

Position signal loss: check cable breakage, connector loose or pin oxidation. Random position jump: verify shielding grounding and separate routing from power cables. Encoder alarm: inspect connector pin definition and cable integrity.

Product Brief

7389-006/-2 is Dutch DELEM dedicated shielded encoder feedback cable for Modusys system. It transfers linear encoder real-time position signal to DM axis module to ensure ram synchronization, classic spare part for legacy sheet metal bending machine overhaul.
