Bently Nevada 2001-400-150-246-280-20-100000-1-0-00 Vibration Accelerometer Unit

Module Feature

2001-400-150-246-280-20-100000-1-0-00 is the full order code of Bently Nevada 2001 series loop-powered vibration accelerometer transmitter.

The internal piezoelectric sensing element converts mechanical vibration acceleration signal into electrical signal, after built-in amplification and filtering, outputs 4-20mA analog signal proportional to vibration velocity. Compact stainless steel housing, threaded mounting base, integrated cable or flying lead option. It is widely used for centrifugal pumps, fans, blowers and gearboxes vibration condition monitoring, signal access to DCS, PLC or local vibration monitor. Widely stocked as maintenance spare for power plant, refinery and water treatment rotating equipment skid.

Working principle

When equipment vibrates, the piezoelectric crystal inside accelerometer generates tiny charge signal.

The on-board conditioning circuit amplifies, filters and converts the vibration signal into standard 4-20mA current signal. 4mA corresponds to zero vibration, 20mA corresponds to full scale vibration value. The signal transmits to the control system through two-wire loop cable, and the loop also provides working power for the sensor.

Onboard components

Piezoelectric sensing chip, signal conditioning PCB, surge protection circuit, stainless steel housing, internal insulation assembly, M6/M8 mounting thread, cable sealing gland.

LED indicators

No built-in LED; vibration value is displayed by external monitor or DCS screen.

Hardware self‑diagnosis

Detects loop open, short circuit and signal out of range. Calibration is performed by vibration shaker table.Programming softwareNot applicable, fixed-range analog transmitter.

Electrical & Process Parameters

Model:2001-400-150-246-280-20-100000-1-0-00 Brand:Bently Nevada (Baker Hughes) Device type:Loop powered vibration accelerometer transmitter Function:Continuous vibration monitoring for rotating machinery

Mechanical & Structure

Mounting:Thread stud direct mount on equipment housing Protection class:IP67 Housing:316 stainless steel sealed enclosure

Environmental

Operating temperature:-40℃ ~ +120℃ Storage temperature:-40℃ ~ +120℃ Ambient humidity:5~95% non‑condensing

Certification:CE, ATEX optional Status:Original Bently Nevada machinery vibration spare

Installation

Clean equipment mounting surface before installation.

Torque sensor to specified value, wire two-wire 4-20mA loop, confirm loop power polarity, test vibration reading and alarm threshold after commissioning.

Interface

4-20mA two-wire loop terminals, stud mounting thread.

Diagnostic

Signal fixed at 4mA: Sensor internal open, loop power missing. Signal saturated at 20mA: Severe equipment vibration, sensor damaged. Unstable reading: Mounting loose, cable damaged, ground interference.

Product Brief2001-400-150-246-280-20-100000-1-0-00 transmitter, Bently Nevada 2001 series 4-20mA vibration accelerometer spare for pump and fan condition monitoring.
