Goodrich 7A1508-125 Aircraft Slide-Raft Evacuation Unit

Module Feature

7A1508-125 is Goodrich integrated slide‑raft emergency evacuation assembly, designed for Airbus A330 and A340 wide‑body aircraft, right‑hand configuration for Door 1 and Door 4 exit positions. It combines evacuation slide and buoyant life raft into one stowed pack. Once deployed, it can be used as evacuation slide on land emergency, and converts into life raft for water ditching survival. It is subject to FAA / EASA airworthiness directives and Goodrich service bulletins, requires periodic overhaul, pressure relief valve inspection and functional test. It belongs to ITAR‑controlled aviation safety critical component, commonly supplied as overhauled, serviceable aviation spare part.

Working principle

The deployment lanyard links to aircraft door mechanism. When the door opens under emergency condition, the lanyard pulls the inflation valve of high‑pressure gas cylinder. Gas rapidly fills the inflatable fabric structure. On land, it forms a steep evacuation slide for passengers to slide down quickly. In water ditching scenario, it transforms into enclosed buoyant life raft. Built‑in pressure relief valve prevents overpressure damage.

Onboard components

Inflatable fabric bladder assembly, high‑pressure inflation gas cylinder, deployment lanyard and girt assembly, pressure relief safety valve, buoyancy chamber, boarding ramp, stowage protective pack, survival kit storage compartment.

LED indicators

No LED indicators. Inspect inflation cylinder pressure gauge, fabric integrity and expiry marking visually.

Hardware self‑diagnosis

No electronic self‑diagnosis function. Maintenance inspection includes fabric leakage, inflation cylinder pressure, relief valve sealing, deployment lanyard integrity. Must comply with airworthiness directive and service bulletin requirements.

Programming software

No configuration software. Operation and maintenance follow aircraft AMM manual and Goodrich service bulletin.

Electrical & Process Parameters

Model:7A1508-125 Brand:Goodrich Device type:Aircraft Integrated Slide‑Raft Evacuation Assembly Applicable aircraft:Airbus A330, A340 Door position:Door 1 / Door 4, Right Hand Certification:TSO‑C69 Function:Land evacuation slide and water ditching life raft dual‑purpose emergency escape equipment

Mechanical & Structure

Mounting:Installed inside aircraft door stowage compartment Protection class:Aviation safety equipment stowed in aircraft interior Housing:Protective stowage pack container

Environmental

Operating temperature:-55℃ ~ +70℃ Storage temperature:-55℃ ~ +85℃ Ambient humidity:5~95% non‑condensing Certification:FAA / EASA airworthiness compliant, ITAR controlled Status:Aviation critical spare assembly, overhaul inspection required before installation

Installation

Install packed assembly inside aircraft door compartment, fix girt mounting interface, connect deployment lanyard linkage with door mechanism. Complete ground deployment test after installation, confirm compliance with service bulletin and airworthiness directive before return to service.

Interface

Aircraft door girt mechanical mounting interface, deployment lanyard linkage mechanism.

Diagnostic

Slow inflation or insufficient pressure:Gas cylinder pressure insufficient or fabric bladder leakage. Relief valve continuous venting:Valve seal failure, mandatory AD inspection item. Failed auto deployment:Lanyard routing error, jam or friction problem. Fabric abrasion and leakage:Replace or send to overhaul workshop.

Product Brief

Goodrich 7A1508-125 slide‑raft evacuation assembly, right‑hand for Airbus A330/A340 Door 1 & 4, dual‑purpose land evacuation slide and ditching life raft, critical aviation safety spare subject to airworthiness periodic overhaul.
