VMIC VMIC5 Shotgun Microphone

Module Feature

VMIC5 is a professional on-camera supercardioid shotgun condenser microphone developed by VMIC. It adopts supercardioid directional pickup pattern to suppress side and rear ambient noise,focusing sound capture on the subject in front. Built-in 2000 mAh rechargeable lithium battery delivers up to 150 hours continuous working time. Two gain modes (0 dB / +10 dB) and 150 Hz low-cut filter are selectable via physical switch to reduce wind and low-frequency rumble noise. Equipped with integrated shock mount to isolate mechanical vibration noise from camera body. 3.5 mm TRS output port for camera connection and independent headphone monitoring jack for real-time audio preview. Built-in BIT self-check circuit verifies battery level and microphone circuit integrity after power-on. Rugged metal housing with windscreen,shock and vibration screened for outdoor shooting environment,widely used in field video interview,documentary recording and portable test system audio capture.

Working principle

Sound wave enters the microphone capsule and converts acoustic signal into analog electrical signal. The onboard preamplifier adjusts gain according to switch setting; low-cut filter attenuates low-frequency noise below 150 Hz. Analog audio signal outputs via 3.5 mm TRS cable to camera or recorder. BIT circuit detects battery voltage and capsule signal status and indicates power status via LED. Shock mount absorbs mechanical vibration to avoid noise coupling.

Onboard components

Condenser microphone capsule,pre-amplifier circuit,150 Hz high-pass filter,2000 mAh rechargeable lithium battery,gain selector switch,low-cut switch,3.5 mm TRS/TRRS interface,headphone monitoring port,shock mount assembly,windscreen,power status LED array,BIT battery detection hardware.

LED indicators

LED indicators for power on,low battery and working status.

Hardware self-diagnosis

Visual inspection of housing,cable and connectors;BIT battery voltage detection;audio signal output test;3.5 mm port continuity validation.

Programming software

No driver or configuration software required,hardware switch operation only.

Electrical & Process Parameters

Model: VMIC5 Brand: VMIC Device type: On-camera supercardioid shotgun condenser microphone Polar pattern: Supercardioid Battery: Built-in 2000 mAh rechargeable lithium battery Battery life: Up to 150 h continuous operation Gain selection: 0 dB / +10 dB High-pass filter: 150 Hz low-cut Audio interface: 3.5 mm TRS output,3.5 mm headphone monitor Control mode: Hardware switch control,built-in BIT battery self-check,shock mount vibration isolation Power supply: Built-in rechargeable battery,USB-C charging Cooling: Natural convection cooling Protection: Overcharge / over-discharge battery protection Mounting: Camera hot shoe shock mount locking Protection class: Metal housing with foam windscreen

Mechanical & Structure

Mounting: Camera hot shoe mount with integrated shock mount Protection class: Metal body with foam windscreen

Environmental

Operating temperature:-10℃ ~ +50℃ Storage temperature:-40℃ ~ +70℃ Ambient humidity:20~80% non-condensing Certification: CE compliant Status: VMIC on-camera supercardioid shotgun condenser microphone

Installation

Align shock mount with camera hot shoe and tighten locking knob. Install foam windscreen on microphone head. Charge via USB-C before first use. Select gain and low-cut mode according to scene. Connect 3.5 mm TRS cable between microphone and camera audio input. Power on microphone,run BIT battery check before recording.

Interface

USB-C charging port,3.5 mm TRS audio output,3.5 mm headphone monitoring jack,physical control switches.

Diagnostic

No sound output: battery exhausted or loose 3.5 mm cable connection. BIT low battery alert: recharge via USB-C. Excessive low-frequency noise: low-cut filter not enabled or windscreen missing. Audio distortion: +10 dB gain overloaded by loud sound source.

Product Brief

VMIC VMIC5 on-camera shotgun microphone,supercardioid pickup pattern,built-in 2000 mAh battery with 150 h runtime,selectable gain and 150 Hz low-cut filter,equipped with shock mount and BIT battery self-check,suitable for field interview and portable test system audio acquisition.
