Siemens QLRTMBAN Resistance Temperature Module

Technical SpecificationsModel:QLRTMBAN (16207-63/5) Brand:Siemens Product Type:RTM Resistance Temperature Module System:QUADLOG Safety Instrumented System / APACS+ DCS System Power Supply:24V DC Sensor Type:RTD resistance temperature detector Mounting:Rack mount Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:2.45kg Dimension:40mm260mm310mm

System compatibilityQLRTMBAN belongs to Siemens Moore QUADLOG SIS series. It works with QLCCM safety controller and matched marshalling termination boards, dedicated for RTD temperature signal collection in QUADLOG safety instrumented system, compatible with APACS+ DCS platform.

FunctionThis RTM resistance temperature module acquires temperature signals from field RTD sensors. It converts resistance variation of RTD probes into digital temperature values and transmits data to QUADLOG safety controller via backplane bus. It is used for safety-related temperature measurement, supports per-channel line fault detection, wire break and short circuit diagnosis, provides temperature data for safety interlock and ESD protection judgment.

InstallationPower off the rack chassis before installation. Insert the module into designated rack slot and lock the front latch. Connect ribbon cable between module and marshalling termination assembly, wire field RTD temperature sensors to terminal assembly. Configure sensor type and safety parameters via QUADLOG engineering software after power on, complete SIF loop test before online operation.

InterfaceBackplane bus connector, ribbon cable port for marshalling board, front LED indicators for power, run, fault and each channel status.

FeatureQUADLOG dedicated safety RTD temperature input module, multi-channel RTD acquisition, continuous per-channel circuit fault diagnosis, galvanic isolation, Class I Division 2 hazardous area certification. Obsolete legacy spare part, used for QUADLOG SIS safety temperature monitoring loop maintenance and replacement.

DiagnosticNo power: check rack 24V DC power supply and backplane contact. Abnormal temperature reading: inspect RTD sensor continuity, wiring and channel configuration. Module fault: read diagnostic codes via QUADLOG software, check wire break or short circuit alarm.

Product BriefSiemens QLRTMBAN is QUADLOG series RTM resistance temperature module, widely used in petrochemical, power and pulp & paper industries for safety instrumented system RTD temperature signal acquisition and monitoring.
