SIEMENS MOORE 16413-1-3 MNI/MBI MNET Interface Module

Technical SpecificationsModel:16413-1-3 Brand:SIEMENS MOORE Product Type:MNI/MBI Combo MNET Communication Interface Module System:APACS+ / QUADLOG DCS System Power Supply:24V DC Mounting:Rack mount Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:0.7kg Dimension:35mm220mm235mm

System compatibility16413-1-3 is compatible with SIEMENS MOORE APACS+ and QUADLOG distributed control system. It is installed in APACS rack, serves as MNET bus interface to realize bidirectional data exchange between engineering workstation and DCS controller racks.

FunctionThis MNI/MBI combo interface module implements APACS MNET bus protocol. It uploads real-time process variables, alarm data and controller operating status; downloads control configuration and parameter modification commands to APACS controllers. It supports online program editing, real-time monitoring and system fault diagnosis for APACS+ DCS platform.

InstallationPower off the rack chassis before installation. Insert the module into designated rack slot and lock the front latch. Connect MNET communication cable, set station address, configure communication parameters via APACS engineering software after power on.

InterfaceBackplane bus connector, MNET communication port, front LED status indicators for power, run and fault.

FeatureIntegrated MNI and MBI dual function interface, reliable MNET bus transmission, built-in communication fault diagnosis, galvanic signal isolation. Obsolete legacy spare part, used for APACS+ DCS workstation communication replacement and maintenance.

DiagnosticNo power: check rack 24V DC power supply and backplane contact. Communication offline: inspect MNET cable, terminal resistor and station address setting. Module fault: read diagnostic status via APACS engineering software, check front LED indicators.

Product BriefSIEMENS MOORE 16413-1-3 is APACS+ series MNI/MBI MNET communication interface module, widely used in petrochemical, power and pulp & paper industries for DCS engineering workstation and control rack interconnection.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
