SIEMENS MOORE 16105-40-11 Termination Assembly

Technical SpecificationsModel:16105-40-11 Brand:SIEMENS MOORE Product Type:Discrete Marshalling Termination Assembly System:APACS+ DCS System Power Supply:24V DC Mounting:Cabinet rail mount Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:0.74kg Dimension:35mm102mm356mm

System compatibility16105-40-11 is compatible with SIEMENS MOORE APACS+ distributed control system. It is the matched marshalling termination board for APACS discrete I/O modules, used to connect field switches, relay signals and discrete I/O cards.

FunctionThis marshalling termination assembly routes discrete digital signals between field devices and APACS discrete I/O modules. It provides screw terminals for convenient field cable termination, organizes on/off digital signal wiring, and transfers field status signals to I/O modules via ribbon cable. It also provides basic overcurrent protection for discrete signal loops.

InstallationPower off the rack chassis before installation. Mount the termination assembly on cabinet DIN rail. Connect ribbon cable between this MTA and discrete I/O module. Terminate field discrete cables on screw terminals following wiring drawing. Verify wiring continuity after installation.

InterfaceScrew type field wiring terminals, ribbon cable connector to discrete I/O module, channel status LED indicators.

FeatureDedicated discrete signal marshalling board, easy screw terminal wiring, built-in signal protection, compact cabinet installation. Obsolete legacy spare part, used for APACS+ DCS discrete signal wiring system maintenance and replacement.

DiagnosticSignal loss: check ribbon cable connection and screw terminal tightness. Signal intermittent: inspect field cable shielding and terminal wiring. LED abnormal: verify 24V DC power supply for termination board.

Product BriefSIEMENS MOORE 16105-40-11 is APACS+ series discrete marshalling termination assembly, widely used in petrochemical, power and pulp & paper industries for DCS digital instrument signal wiring.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
