SIEMENS MOORE 15738-120 Mounting Case

Technical SpecificationsModel:15738-120 Brand:SIEMENS MOORE Product Type:Panel Controller Mounting Case Terminal:20 screw terminals Mounting:Panel mount Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:2.3kg Dimension:76mm178mm432mm

System compatibility15738-120 is compatible with SIEMENS MOORE 320,351,352 series standalone panel process controllers. It serves as complete enclosure and terminal base for these loop controllers.

FunctionThis mounting case provides mechanical protection and field wiring terminal interface for panel mounted controllers. 20 screw terminals support power, analog I/O and alarm signal wiring. It fixes the controller unit inside cabinet panel, organizes field instrument cables and protects internal circuit from dust and mechanical impact.

InstallationCut off power before installation. Embed the housing into cabinet panel and fasten mounting brackets. Route field cables and terminate wires on 20 screw terminals according to wiring drawing. Insert controller main unit into the case and lock in place.

Interface20 screw type wiring terminals, panel mounting lugs, internal slot for controller mainboard.

FeatureMetal housing design, 20 screw terminals for multi-signal wiring, robust mechanical structure, dust protection, easy field wiring and maintenance. Obsolete legacy spare part, used for Moore panel controller enclosure replacement.

DiagnosticLoose signal: check screw terminal tightness and cable crimp. Mechanical installation abnormal: inspect panel cutout dimension and mounting clip. Short circuit risk: check terminal insulation and cable shielding.

Product BriefSIEMENS MOORE 15738-120 is a metal mounting case with 20 terminals for 320/351/352 series panel controllers, widely used in petrochemical, boiler and water treatment plants for loop controller installation.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
