SEW DOP11A-10 Operator Terminal

Technical SpecificationsModel:DOP11A-10 Brand:SEW Product Type:Operator HMI Terminal Part No:8248001 Weight:0.42kg Dimension:142mm90mm46.5mm Display:2×20 character monochrome backlit LCD Keyboard:Membrane keypad with numeric and function keys Power supply:DC 24V,200mA Memory:64kByte Flash EEPROM Communication:RS232, RS422, RS485 (two interfaces usable simultaneously) Front protection class:IP65 Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibilityDOP11A-10 belongs to SEW DOP11A series HMI terminal. It can communicate with SEW MOVIDRIVE series inverters and mainstream PLC systems. Widely applied on packaging machines, conveyor systems and automated assembly lines, for legacy automation system maintenance and spare replacement.

FunctionThis text-type operator terminal realizes on-site data visualization, parameter modification, equipment start-stop control and fault alarm display. It supports project download via HMI-Builder software from PC. Multiple serial communication ports enable connection with SEW drives or third-party controllers. It stores user project in flash memory, no battery required for project retention.

InstallationCut off 24VDC power before installation. Install via cabinet panel cutout mounting, secure with mounting clips. Wire 24V power and serial communication cables. Separate communication wiring from high-power cables to reduce interference. Download HMI project from PC through serial port before commissioning.

InterfaceRS232, RS422, RS485 serial ports, DC24V power terminals.

FeatureSEW DOP11A-10 compact text HMI terminal, robust membrane keypad. IP65 front panel for dust and splash protection, suitable for workshop environment. Multiple serial interfaces for flexible connection with drives and PLC. Flash memory retains project without backup battery. Discontinued legacy spare part, only for DOP11A series HMI maintenance replacement. Suitable for simple motion control visualization and local operation.

DiagnosticNo LCD backlight: missing 24VDC supply or loose power terminal; Communication failure: wrong serial wiring, mismatched baud rate or damaged cable; Keypad no response: membrane keypad damage; Project lost: flash memory failure.

Product BriefSEW DOP11A-10 is DOP11A series text operator HMI terminal with 2×20 backlit LCD and membrane keypad, used for local operation, data monitoring and fault display of SEW drive and PLC automation systems.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
