SEW DBG11A-01 Operator Keypad

Technical SpecificationsModel:DBG11A-01 Brand:SEW Product Type:Drive Operator Keypad Display:Plain text LCD display Connector:14-pin female connector Operating temperature:-20℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Mounting:Front panel mounting on inverter Certification:CE

System compatibilityDBG11A-01 is the original operation panel for SEW MOVIDRIVE MD60A series servo inverters. It can be directly plugged into the drive front slot. Widely used for on-site commissioning, parameter backup and troubleshooting for packaging, conveyor and automated production lines, legacy SEW drive system maintenance and spare replacement.

FunctionThis keypad is used for local operation of MOVIDRIVE MD60A inverters. It supports drive parameter read/write, start/stop control, real-time status viewing, fault code display and fault reset. It can save and upload parameter sets for quick device replacement and commissioning. The plain text LCD shows readable alarm messages instead of simple code numbers, convenient for on-site maintenance.

InstallationCut off the inverter power supply before installation. Align the 14-pin connector and insert DBG11A-01 into the front interface of MOVIDRIVE MD60A. Lock the buckle to fix the panel. Power on the drive after installation, the keypad will automatically communicate with the inverter. After operation, parameters can be saved to the keypad for backup.

Interface14-pin female integrated communication connector, front mounting snap buckle.

FeatureSEW DBG11A-01 compact handheld/onboard keypad. Plain text LCD display for easy reading of status and faults. Simple 6-button layout for parameter modification and drive control. Quick plug and play design, no extra wiring required. Discontinued original spare part, only for MOVIDRIVE MD60A series drive maintenance replacement. Suitable for on-site commissioning and troubleshooting of automation production equipment.

DiagnosticNo display after power on: loose 14-pin connector or keypad damage; Cannot modify parameters: parameter lock function activated; Communication intermittent: poor contact of connector pins; Fault text not displayed: incompatible drive firmware version.

Product BriefSEW DBG11A-01 is MOVIDRIVE MD60A series dedicated operator keypad with plain text LCD, used for local parameter setting, status monitoring and fault diagnosis of SEW servo inverters.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
