SEW CM71S-BR-HR-KTY-RH5L-SB60 Servo Motor

Technical SpecificationsModel:CM71S-BR-HR-KTY-RH5L-SB60 Brand:SEW Product Type:Synchronous Permanent Magnet Servo Motor Frame size:71S Cooling:Natural convection Protection class:IP65 Insulation class:F Temperature sensor:KTY84-130 Feedback:RH5L resolver Brake:BR holding brake Connector type:SB60 combined power & signal connector Operating temperature:-20℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibilityCM71S-BR-HR-KTY-RH5L-SB60 belongs to SEW CM series servo motor. Compatible with SEW MOVIDRIVE series servo drives. Widely used in packaging machines, material handling, portal axes and automated assembly lines, for legacy SEW servo system maintenance and spare replacement.

FunctionThis high dynamic synchronous servo motor adopts rare-earth permanent magnet design, features low rotor inertia and high overload capacity. Equipped with BR spring-applied holding brake for shaft locking when power off. KTY temperature sensor monitors winding temperature in real time to prevent overheating damage. RH5L resolver provides high reliable position and speed feedback for servo controller. SB60 integrated connector simplifies wiring of power cable and feedback cable.

InstallationDisconnect drive power before installation. Mount motor by flange or foot mounting. Align coupling or gear unit carefully, avoid radial and axial over load. Route power cable and feedback cable separately to reduce interference. Wire KTY temperature signal and brake control circuit to servo drive. Perform motor identification and encoder offset calibration before commissioning.

InterfaceSB60 combined power and feedback connector, brake control terminals, KTY temperature sensor terminals.

FeatureSEW CM71S compact servo motor, low inertia design for fast acceleration and deceleration. Built-in spring holding brake, safe static shaft retention. Resolver feedback, strong anti-vibration and anti-interference ability, suitable for harsh workshop environment. KTY winding temperature protection. IP65 enclosure, dust-proof and splash-proof. Discontinued legacy spare part, only for SEW servo drive system maintenance replacement. Suitable for packaging automation, logistics handling and automated machine tool axes.

DiagnosticMotor overheat alarm: excessive load, poor ventilation or damaged KTY sensor; Position tracking error: resolver wiring fault or resolver damage; Brake cannot release: insufficient brake supply voltage; Motor no torque: power connector loose or winding failure; Vibration & noise: misalignment or bearing wear.

Product BriefSEW CM71S-BR-HR-KTY-RH5L-SB60 is CM series 71S frame synchronous permanent magnet servo motor, fitted with holding brake, KTY temperature sensor, RH5L resolver and SB60 connector, matched with MOVIDRIVE servo inverters for automation motion control.

DisclaimerAll parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
