Schneider M22A-24V SpaceLogic Modulating Globe Valve Actuator Unit

Feature & Principle

This electromechanical modulating actuator receives analog control signal from building controller, adjusts stem position continuously to change valve opening, realizing stepless regulation of chilled water or hot water flow. It has built-in position feedback, overload protection and IP65 waterproof housing, suitable for stable flow adjustment in heating, ventilation and air conditioning systems.

Specifications

Model: M22A-24V Brand: Schneider Electric Series: SpaceLogic M22A Power Supply: 24V AC Control Signal: 0-10V DC / 0-20mA Output Thrust: 2200N Stroke: 50mm Protection: IP65 Applicable Valve: V222, V292, V321 DN125~DN150 globe valve Certification: CE

Components & Diagnostics

Servo motor, reduction gear set, position feedback sensor, control circuit board, plastic housing and valve connection bracket. Common faults: motor stalling, feedback signal drift, gear wear, wiring loose and actuator no response.

Product Brief

M22A-24V actuator, Schneider HVAC spare widely used for central air conditioning, heating system and industrial water system globe valve flow regulation.
