Sanyo Denki P50B07040DXS00 E AC Servo Motor

Module Feature

Sanyo Denki P50B07040DXS00 E is AC brushless servo motor adopting low inertia rotor design. Rated power 400W, AC200V input class. Equipped with built-in high resolution incremental rotary encoder for closed loop position feedback. Compact flange mounting structure, excellent low speed running stability, high torque density. No built-in holding brake. Reinforced bearing assembly, strong vibration resistance. Widely applied to horizontal axis motion positioning in semiconductor wet bench and chemical delivery automation equipment.

Working principle: The matched servo driver outputs three-phase AC power to motor windings. Built-in encoder feeds back rotor angle and speed signal continuously to servo drive. Driver dynamically adjusts output current to realize precise control of torque, speed and position. Without power-off holding brake, external mechanical stop should be adopted for vertical load application.

Onboard components:Motor stator and rotor assembly,built-in incremental rotary encoder,high precision bearing set,main housing,power connector,encoder signal connector

LED indicatorsNo LED indicators on motor body; status LEDs are located on matched servo drive unit.

Hardware self-diagnosis

Visual inspection of shaft surface,connectors and cable insulation; winding continuity test; insulation resistance test; encoder signal waveform check; shaft rotation smoothness inspection.

Programming software

Sanyo Denki servo configuration software for motor parameter setting,gain auto tuning and fault alarm log reading.

Electrical & Process Parameters

Rated power:400W Rated voltage:AC200V Rotor type:Low inertia Feedback:Built-in incremental encoder Brake:Without holding brake Cooling:Natural air cooling

Mechanical & Structure

Mounting:Flange mount Protection class:IP65 (shaft and connector area) Shaft:Keyway shaft

Environmental

Operating temperature:0℃ ~ +40℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:Sanyo Denki low inertia AC servo motor

System compatibility

Compatible with corresponding Sanyo Denki servo drive series,used for linear and rotary axis positioning of automation equipment.

Function

P50B07040DXS00 E servo motor manufactured by Sanyo Denki. It provides accurate rotary motion and position control. Winding damage,encoder failure or shaft misalignment will trigger servo alarm and stop movement. It is motion actuator for semiconductor wet bench and chemical delivery automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off servo drive system. Align motor shaft and load coupling,fasten flange mounting bolts. Wire power cable and encoder cable. Set servo parameters,complete jogging test and positioning verification before formal operation.

Interface3-phase power connector,encoder signal connector on housing of P50B07040DXS00 E.

Diagnostic

Motor no rotation:Power wiring error or servo enable signal missing. Position drift:Loose coupling,encoder damage or servo gain mismatch. Overheat alarm:Overload load or bearing wear. Abnormal running noise:Bearing damage or shaft misalignment.

Product Brief

P50B07040DXS00 E Sanyo Denki 400W low inertia AC servo motor,AC200V,built-in incremental encoder,flange mount,no holding brake,for semiconductor wet bench and chemical delivery automation motion positioning.
