Sanyo Denki 60BA075FFW12 AC Servo Motor

Module Feature

Sanyo Denki 60BA075FFW12 belongs to SANMOTION BA series AC brushless servo motor. Rated power 750W, AC200V power class, medium inertia rotor design. Built-in 24V electromagnetic power-off holding brake, can lock shaft when brake power is cut off, suitable for vertical axis applications to prevent load falling. Built-in high resolution rotary encoder for closed-loop position feedback. Standard 60mm square flange, compact body structure, high torque density and low torque ripple. High rigidity double ball bearing assembly, excellent vibration resistance and stable low-speed running performance. Widely used for medium load vertical positioning axis in semiconductor wet bench and chemical delivery automation equipment.

Working principle: The matched servo amplifier outputs three-phase AC power to motor windings. The built-in encoder continuously feeds rotor angle and speed signal back to servo drive. The drive performs real-time closed-loop calculation and adjusts output current to realize precise torque, speed and position control. When brake power supply is disconnected, the 24V power-off brake locks the motor shaft to hold vertical load securely.

Onboard components:Motor stator & rotor assembly,built-in high resolution rotary encoder,24V electromagnetic holding brake,heavy duty double ball bearing set,aluminum alloy housing,3-phase power connector,encoder feedback connector,brake wiring terminal

LED indicatorsNo LED indicators on motor body; status LEDs are located on matched servo drive unit.

Hardware self-diagnosis

Visual inspection of shaft surface,connector pins and cable insulation; winding continuity and insulation resistance test; encoder signal waveform inspection; brake release and holding functional test.

Programming software

Sanyo Denki SANMOTION servo setup software for motor parameter auto recognition, servo gain tuning and alarm log reading.

Electrical & Process Parameters

Rated power:750W Rated voltage:AC200V Rotor type:Medium inertia Feedback:Built-in high resolution rotary encoder Brake:24V DC electromagnetic holding brake Cooling:Natural air cooling

Mechanical & Structure

Mounting:60mm square flange mount Protection class:IP65 (shaft and connector area) Shaft:Keyway shaft

Environmental

Operating temperature:0℃ ~ +40℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:Sanyo Denki SANMOTION BA series AC servo motor

System compatibility

Compatible with Sanyo Denki SANMOTION R / PQM series servo drives for automation equipment medium load vertical axis positioning.

Function

60BA075FFW12 servo motor manufactured by Sanyo Denki. It delivers high precision rotary motion and positioning control for medium vertical load axis. Winding damage, encoder failure or brake malfunction will trigger servo alarm and stop movement. It is compact motion actuator for semiconductor wet bench and chemical delivery automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off servo drive system. Align motor shaft and load coupling, fasten flange mounting bolts securely. Wire motor power cable, encoder feedback cable and 24V brake control wiring. Configure servo parameters via SANMOTION software, perform brake functional test, jog test and positioning verification before formal operation.

Interface3-phase power connector, encoder feedback connector, 24V brake control connector on housing of 60BA075FFW12.

Diagnostic

Motor cannot rotate:Power wiring error, servo enable signal missing or brake not released. Positioning inaccuracy:Encoder fault, loose coupling or servo gain mismatch. Overheat alarm:Overloaded load, poor ventilation or bearing wear. Abnormal running noise:Bearing damage or shaft misalignment between motor and load.

Product Brief

60BA075FFW12 Sanyo Denki SANMOTION BA series 750W AC servo motor,AC200V,built-in 24V holding brake,60mm square flange mount,for semiconductor wet bench and chemical delivery medium load vertical axis precision motion control.
