P54531JB6M0710M Filter Element

Feature & Principle

It is a pleated glass fiber hydraulic filter element. When contaminated hydraulic oil passes through the filter medium, solid particles are trapped on the surface and inside the depth media. It keeps oil cleanliness within the required ISO code, protects hydraulic pumps, servo valves and actuators from abrasive wear. The structural support inner and outer metal sleeves prevent collapse under differential pressure. It is directly interchangeable for many standard filter housings.

Specifications

Model: P54531JB6M0710M Type: Hydraulic filter element Filter media: Glass fiber Core material: Perforated metal Seal material: Nitrile / FKM optional Working medium: Hydraulic oil, lubrication oil Max differential pressure: 21 bar Operating temperature: -25℃ ~ +100℃ Installation: Screw / flange filter housing Application: Hydraulic station, injection molding machine, steel mill, construction machinery, wind turbine hydraulic system Certification: CE

Components & Diagnostics

Pleated filter media, inner support tube, outer protective sleeve, end caps, sealing gasket. Common faults: element blocked, seal leakage, media rupture, bypass valve open due to high clogging.

Product Brief

P54531JB6M0710M hydraulic filter element, industrial lubrication and hydraulic system spare widely used for hydraulic station overhaul and replacement.
