S220-2-U-1-2-C-B-H-P-12-3 Control Valve

Feature & Principle

It is a spring-diaphragm type pneumatic regulating valve. The air signal acts on the diaphragm to balance the spring force and drive the valve plug to change the flow area. It can stabilize downstream pressure or flow rate automatically when inlet pressure or flow fluctuates. This full model code defines body material, port size, action mode, seal type, mounting and pressure range. It can be matched with positioner for high-precision modulation control.

Specifications

Model: S220-2-U-1-2-C-B-H-P-12-3 Series: S220 Operation: Pneumatic spring diaphragm Port size: Defined by suffix code Seal: Soft seal for tight shut-off Mounting: In-line pipeline installation Protection: IP65 Media: Compressed air, inert gas, clean liquid Application: Petrochemical, gas supply, test bench, process flow control Certification: CE

Components & Diagnostics

Valve body, diaphragm assembly, spring pack, valve plug and seat, adjustment screw, air signal port. Common faults: seat leakage, diaphragm rupture, unstable regulation, signal port blockage.

Product Brief

S220-2-U-1-2-C-B-H-P-12-3 pneumatic regulating valve, process control spare widely used for industrial pipeline regulation loop overhaul and replacement.
