MOOG B97036-001 7 Pin Threaded Circular Connector

Technical Specifications

Model:B97036-001

Brand:MOOG

Product type:7 Pin Threaded Circular Metal Mating Connector

Structure:Metal shell,thread locking,gold-plated contact pins

Pin count:7 pins

Protection class:IP65(mated)

Cable outer diameter:7~11mm

Dimension:46mm*17mm

Weight:0.042kg

Operating temperature:-20℃ ~ +120℃

Storage temperature:-40℃ ~ +130℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

B97036-001 is MOOG 7-pin threaded servo valve mating connector.It matches MOOG D633,D634 series servo valves,widely used in steam turbine DEH system,fatigue test bench and precision hydraulic servo system.It is electrical spare part for servo valve overhaul.

Function

B97036-001 threaded connector transmits differential current signal for torque motor between servo amplifier and servo valve.Thread locking design provides stable anti-vibration connection under industrial vibration environment.

Installation

Strip cable and crimp gold-plated contacts,insert pins into connector housing.Screw the threaded ring to lock with valve socket.Check wiring continuity and insulation after assembly.Shielded cable is recommended.Take anti-static protection during handling.

Interface

‑7 pin cavity,thread locking interface

‑Connector laser marking label

Feature

MOOG compact 7 pin metal servo valve connector.Typical faults:pin corrosion,cable fracture,poor contact.Inspect pin condition during maintenance.

Diagnostic

Fault phenomenon:signal interruption,jitter,servo valve no response.Check connector pins,cable crimp and threaded locking condition.

Product Brief

B97036-001 is MOOG 7-pin threaded circular metal mating connector for torque motor signal transmission of D633/D634 servo valves.It is essential electrical connection spare part for industrial electro-hydraulic servo system maintenance and replacement.
