MOOG B97027-012 12 Pin Bayonet Mating Connector

Technical Specifications

Model:B97027-012

Brand:MOOG

Product type:12 Pin Bayonet Circular Metal Mating Connector

Standard:MIL-C-26482

Structure:Metal shell,bayonet quick lock,gold-plated contact pins

Pin count:12 pins

Protection class:IP65(mated)

Cable outer diameter:8~13mm

Dimension:52mm*20mm

Weight:0.05kg

Operating temperature:-20℃ ~ +120℃

Storage temperature:-40℃ ~ +130℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

B97027-012 is MOOG 12-pin bayonet servo valve mating connector.It is designed for MOOG D661 series servo valves with integrated electronics,widely used in steam turbine DEH,fatigue test bench and high-precision hydraulic servo system.It is electrical spare part for servo valve overhaul.

Function

B97027-012 bayonet connector transmits power supply,analog command signal and spool position feedback signal between controller and servo valve.Bayonet locking structure provides anti-vibration and reliable connection in harsh industrial environment.

Installation

Strip cable and crimp gold-plated contacts,insert pins into connector housing.Twist bayonet ring to lock with valve socket.Check wiring continuity and insulation after assembly.Shielded cable is recommended.Take anti-static protection during handling.

Interface

‑12 pin cavity,bayonet locking interface

‑Connector laser marking label

Feature

MOOG MIL standard 12 pin bayonet metal connector.Typical faults:pin oxidation,cable breakage,poor contact.Inspect pin status during maintenance.

Diagnostic

Fault phenomenon:signal fluctuation,intermittent communication,servo valve unstable operation.Check connector pins,cable crimp and bayonet locking status.

Product Brief

B97027-012 is MOOG 12-pin bayonet circular metal mating connector for D661 series servo valve power and signal transmission.It is essential electrical connection spare part for industrial electro-hydraulic servo system maintenance and replacement.
