MODICON MM-PMC1-300 Motion Processor Module

Technical SpecificationsModel:MM-PMC1-300 Brand:MODICON Product Type:MM Series Multi-Axis Motion Control Processor Module Control Function:Point positioning,interpolation,electronic cam,speed and torque control Backplane Power:5V DC supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.3kg Dimension:260mm140mm30mm Protection:IP20

System compatibilityMM-PMC1-300 belongs to MODICON MM series motion processor module. Compatible with MODICON 984 series CPU,backplane and matching MODICON servo drive units. It cooperates with MODICON servo motors to realize multi-axis synchronous motion control. Suitable for machine tool,packaging equipment,textile machinery,automated assembly line multi-axis motion control renovation and replacement as industrial spare part.

FunctionMM-PMC1-300 multi-axis motion processor module. It receives motion commands from PLC CPU and independently executes closed-loop motion control. It outputs analog or pulse command signals to servo drives and reads real-time encoder feedback. It supports linear interpolation,circular interpolation,electronic cam and axis synchronization functions. Widely used for high-precision multi-axis motion control of automation equipment, serving as reliable motion control spare part.

InstallationCut off rack and servo drive power before installation. Insert MM-PMC1-300 motion module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect command output cables and encoder feedback cables to servo drives. Configure axis parameters,complete servo tuning and motion function test before formal operation.

InterfaceBackplane bus connector,servo command port,encoder feedback port,status and fault LED indicators for MM-PMC1-300 MODICON motion processor module.

FeatureMODICON MM-PMC1-300 motion processor module,independent motion calculation,rich motion instruction set,support electronic cam and multi-axis synchronization,standard single slot rack design,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON multi-axis motion automation system maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for MM-PMC1-300. Axis motion abnormal: check command cable,encoder wiring,axis parameter and servo enable signal. Synchronization error: inspect cam table configuration and mechanical load condition. Motion overrun alarm: check limit switch wiring and soft limit parameter setting. Hardware fault warning: inspect backplane power supply and internal circuit damage.

Product BriefMM-PMC1-300 is MODICON MM series multi-axis motion processor module. It is responsible for multi-axis interpolation and synchronous motion control of servo system,classic spare part for legacy MODICON industrial motion equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
