MODICON MM-PM10-300 HMI Operator Panel

Technical SpecificationsModel:MM-PM10-300 Brand:MODICON Product Type:PanelMate Plus Series HMI Operator Terminal Display:4.75 inch CRT display Power Supply:18~30V DC Power Consumption:11W Communication:Modbus Mounting:Panel cutout installation Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.81kg Dimension:260mm200mm80mm Protection:IP65 front panel,IP20 rear side

System compatibilityMM-PM10-300 belongs to MODICON PanelMate Plus series HMI terminal. Compatible with MODICON 984 / Quantum PLC system via Modbus. Suitable for packaging machinery,water treatment,chemical plant,conveyor line on-site operation and monitoring renovation and replacement as industrial spare part.

FunctionMM-PM10-300 industrial CRT human-machine interface. It communicates with MODICON PLC through Modbus protocol,real-time reading of process values,I/O status and fault alarm information. It supports manual operation commands input,parameter setting and alarm record storage. Built-in hardware self-diagnosis function. Widely used for on-site human-machine interaction of industrial automation equipment, serving as reliable HMI spare part.

InstallationCut off power supply before installation. Embed MM-PM10-300 HMI into cabinet panel cutout and fix the fasteners. Connect DC power cable and Modbus communication cable. Configure Modbus station address and screen picture parameters,complete data reading and operation test before formal operation.

InterfaceDC power terminal,Modbus RS485 communication port,CRT display + keypad,status and fault LED indicators for MM-PM10-300 MODICON HMI operator terminal.

FeatureMODICON MM-PM10-300 PanelMate Plus HMI,4.75 inch CRT display,18~30VDC wide range power supply,Modbus communication,front panel IP65 dustproof and waterproof,industrial anti-interference design. This discontinued legacy industrial spare part used for old MODICON PLC automation system on-site monitoring and manual operation maintenance and replacement.

DiagnosticPanel no power: check DC power supply,fuse and loose terminal for MM-PM10-300. No PLC data reading: check Modbus wiring,station address and shielding grounding. CRT screen abnormal: inspect aging of display tube and power board fault. Keypad no response: check membrane keypad damage and internal circuit fault. Intermittent communication loss: check cable aging and electromagnetic interference.

Product BriefMM-PM10-300 is MODICON PanelMate Plus series CRT HMI operator terminal. It connects MODICON PLC for on-site process data display,parameter configuration and manual control,classic spare part for legacy MODICON industrial automation equipment overhaul.
