MODICON ALUMINIUM286 Aluminium Chassis Assembly

Technical SpecificationsModel:ALUMINIUM286 Brand:MODICON Product Type:Aluminium Rack Chassis Assembly Material:Aluminium alloy Mounting:Backplane rack installation,module slot mounting Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:3.1kg Dimension:482mm177mm105mm Protection:IP20

System compatibilityALUMINIUM286 belongs to MODICON classic aluminium rack assembly. Compatible with MODICON 286 series CPU board and matching I/O modules. It is used as mechanical carrier for old MODICON rack PLC system. Suitable for factory production line,water treatment,chemical industry old automation cabinet renovation and replacement as industrial spare part.

FunctionALUMINIUM286 aluminium rack chassis. It provides mechanical fixing and support for MODICON backplane,CPU and I/O modules. It forms metal shielding structure to reduce electromagnetic interference for internal control cards. It reserves wiring space and grounding terminal for whole rack system. Widely used as mechanical rack carrier for legacy MODICON PLC control cabinet, serving as reliable chassis spare part.

InstallationCut off all rack power before installation. Fix ALUMINIUM286 aluminium rack on cabinet mounting rail. Install backplane into the rack,insert each PLC module and lock the module fasteners. Complete protective earth connection and check mechanical stability before putting modules into operation.

InterfaceModule slot,backplane mounting position,protective earth terminal for ALUMINIUM286 MODICON aluminium rack chassis.

FeatureMODICON ALUMINIUM286 aluminium alloy rack chassis,high rigidity mechanical frame,metal electromagnetic shielding,standard rack structure,corrosion resistant surface treatment,industrial workshop environment adaptability. This discontinued legacy industrial spare part used for old MODICON 286 PLC system mechanical rack maintenance and replacement.

DiagnosticModule loose: check rack fixing screw and module latch for ALUMINIUM286. Poor shielding effect: inspect earth connection and chassis surface oxidation. Mechanical deformation: check overload extrusion and impact damage. Grounding fault: verify ground wire integrity and chassis contact. Corrosion warning: check damp environment and surface rust.

Product BriefALUMINIUM286 is MODICON aluminium alloy rack chassis assembly. It is the mechanical mounting frame for MODICON 286 series PLC backplane and control modules,classic spare part for legacy MODICON industrial automation equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
