MODICON MM-P10-200 Memory Module

Technical SpecificationsModel:MM-P10-200 Brand:MODICON Product Type:984 Series PLC Program Memory Cartridge Memory Capacity:16K program memory Backup:Built-in lithium battery for data retention Mounting:Plug into CPU memory slot Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.22kg Dimension:110mm45mm18mm Protection:IP20

System compatibilityMM-P10-200 belongs to MODICON 984 series memory cartridge. Compatible with MODICON 984 series CPU such as PC-E984-685 and matching processor modules. It can be inserted directly into CPU memory slot to expand program storage space. Suitable for chemical,water treatment,metallurgy,legacy production line PLC system program storage upgrade and replacement as industrial spare part.

FunctionMM-P10-200 is dedicated memory cartridge for MODICON 984 series PLC. It stores ladder logic user program, system configuration and preset parameter data. The built-in lithium battery keeps data safe when rack power is cut off, prevents program loss caused by power failure. Widely used for PLC program storage and data backup, serving as reliable memory spare part.

InstallationCut off rack power before installation. Open CPU memory cover, insert MM-P10-200 memory cartridge into the memory slot, lock the buckle. Power on and verify program readout before formal operation.

InterfaceGold finger contact for CPU memory slot,battery status indicator for MM-P10-200 MODICON memory cartridge.

FeatureMODICON MM-P10-200 pluggable memory cartridge,built-in lithium battery backup,compact small size,simple installation,protect PLC program against power loss,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 984 PLC system memory maintenance and replacement.

DiagnosticProgram cannot be read: check cartridge insertion,gold finger cleaning and battery voltage for MM-P10-200. Program loss after power off: inspect lithium battery aging and battery voltage. CPU memory fault alarm: check cartridge damage and slot contact failure. Intermittent read error: clean gold finger and check rack vibration. Battery low warning: replace the backup lithium battery.

Product BriefMM-P10-200 is MODICON 984 series pluggable program memory cartridge. It stores PLC user program and configuration data with battery backup, classic spare part for legacy MODICON 984 PLC system overhaul.

Disclaimer:All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
