MODICON 91-00911-05 I/O Module

Technical SpecificationsModel:91-00911-05 Brand:Schneider MODICON Product Type:557VIC Series VIC10400 1U I/O Module Backplane Power:Supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.3kg Dimension:260mm140mm30mm Protection:IP20

System compatibility91-00911-05 belongs to MODICON 557VIC series I/O module. Compatible with MODICON 557VIC series CPU, backplane and matching system components. It can collect field digital and analog signals and receive control commands from PLC processor. Suitable for FactoryMate Plus system,chemical,water treatment,old production line PLC control system renovation and replacement as industrial spare part.

Function91-00911-05 is 1U rack I/O module for MODICON 557VIC PLC. It completes field digital/analog signal collection and control signal output,transfers data between backplane bus and field sensors,actuators. It supports channel status monitoring and built-in overcurrent protection. Widely used for field signal acquisition and output control of industrial automation system, serving as reliable I/O spare part.

InstallationCut off rack power before installation. Insert the 91-00911-05 module into MODICON 557VIC backplane slot and lock the card. Wire field signal cables to module terminal. Set channel configuration parameters,complete channel test before formal operation.

InterfaceBackplane bus connector,field signal terminal block,channel status LED indicators for 91-00911-05 Schneider MODICON I/O module.

FeatureSchneider MODICON 91-00911-05 1U rack I/O module,compact single slot design,built-in overcurrent protection,real-time channel status monitoring,stable operation in industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 557VIC FactoryMate Plus automation system maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 91-00911-05. Signal reading abnormal: check field wiring,channel configuration and terminal connection. Channel no output: inspect actuator wiring and overcurrent protection trigger. Intermittent signal error: check cable shielding,grounding and connector loose fault. Fault alarm: read module diagnostic information through supporting programming software.

Product Brief91-00911-05 is Schneider MODICON 557VIC series VIC10400 1U rack I/O module. It is used for FactoryMate Plus system,realizes field signal collection and control output,classic spare part for legacy industrial automation equipment overhaul.

Disclaimer:All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
