Kollmorgen CR06260 Servo Drive Spare Part

Technical Specifications

Model:CR06260

Brand:Kollmorgen

Part No:CR06260

Product type:Analog servo amplifier

Input voltage:400V AC three phase

Rated output current:20A

Dimension:300mm180mm220mm

Weight:9.8kg

Feedback interface:Resolver / incremental encoder

Mounting:Cabinet rack mounting

Protection class:IP20

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

System compatibility

CR06260 belongs to Kollmorgen CR series analog servo drive family,matched with Kollmorgen AKM and 6SM series servo motors,widely applied in old machine tools,packaging equipment and material handling systems.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

CR06260 is legacy analog servo amplifier.It accepts ±10V analog speed or position command signal,realizes closed-loop motor motion control.It supports resolver and incremental encoder feedback,built-in multi-protection including overcurrent,overvoltage,overtemperature.It is commonly used for retrofitting and repairing old analog machine axes.

Installation

Install CR06260 inside electrical cabinet by rack mounting.Connect three-phase power wiring,motor power cable,feedback cable and analog control signal wiring.Fasten terminals,complete shielding and grounding inspection before power-on test.

Interface

‑3 phase 400V AC power terminal

‑Motor power output terminal

‑Resolver / incremental encoder feedback connector

‑±10V analog command port

‑Digital input and output terminal

‑Shield grounding terminal

Circuit feature

Adopts analog closed-loop control circuit,IGBT power stage,comprehensive fault protection circuit,strong anti-interference performance,suitable for traditional analog motion control equipment.

Feature

CR06260 is obsolete Kollmorgen spare part.Typical faults:IGBT module damage,electrolytic capacitor aging,feedback circuit failure,internal power supply breakdown,connector corrosion.Test DC bus voltage,output three-phase balance and feedback channel before replacement.

Diagnostic

Drive faults will trigger overcurrent,overvoltage or overtemperature alarm;motor no action,position drift,axis abnormal running.

Built‑in function:Analog command processing,motor power amplification,speed and position closed-loop control,fault safety protection,as Kollmorgen legacy machine tool servo drive spare replacement.

Product Brief

CR06260 is Kollmorgen CR series analog servo amplifier,paired with AKM /6SM servo motors for legacy machine tool systems.Confirm power rating,feedback type and control signal before ordering.ESD protection required during handling and installation.
