KEBA RS-091/A Rack Power Supply Module

Technical Specifications

Model:RS-091/A

Brand:KEBA

Product type:Rack mount AC-DC power supply module

Power input:110/230V AC universal input

Power output:24 Vdc,max 5A stable output

Control function:AC-DC power conversion,rack system power supply,overload protection,short-circuit protection,overvoltage protection,power status monitoring,hardware self-diagnosis,fault indication

Communication:Kemro K2 backplane bus status feedback

Mounting:Plug-in rack slot installation

Operating temperature:-10~55℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.42kg

Dimension:260mm70mm30mm

Certification:CE

Protection class:IP20

System compatibility

RS-091/A belongs to KEBA Kemro K2 control system family,matched with KEMRO-BUS-8 backplane,K2 series CPU and I/O modules.Widely applied in injection molding,die-casting machine control cabinets.This is a discontinued legacy power supply module for equipment maintenance spare replacement.

Function

RS-091/A serves as KEBA rack AC-DC power supply module.It converts 110/230V AC industrial power into stable 24Vdc power,supplies continuous and reliable power to all CPU,I/O and functional modules on Kemro K2 backplane.It integrates overload,short-circuit and overvoltage multi-protection mechanism to avoid system module burnout caused by power fluctuation and surge interference.It monitors real-time power operating status and feeds back fault information to the main controller via backplane bus.It acts as the core power supply component for Kemro K2 modular control system.

Installation

Insert RS-091/A into the designated rack slot and lock the latch.Complete AC power input wiring according to wiring drawing.Check wiring correctness and cabinet grounding before power-on.

Interface

‑AC 110/230V power input terminal

‑24Vdc backplane power output terminal

‑Kemro K2 backplane gold finger connector

‑Power status and fault LED indicator

Circuit feature

Built-in ESD and surge suppression circuit,isolated high-efficiency AC-DC conversion design,constant voltage output,strong anti-interference performance for industrial cabinet environment.

Feature

RS-091/A is obsolete KEBA series spare part.Typical failures include no power output,output voltage instability,frequent protection trip,internal circuit aging and pin oxidation.Check module circuit and connector pins before replacement.This module must match Kemro K2 series rack system,direct substitution without inspection is not recommended.

Diagnostic

When overload,short-circuit,overvoltage or internal hardware fault occurs,the module automatically triggers protection mechanism and lights up fault LED to alarm system abnormality.

Built‑in function:AC-DC power conversion,rack system stable power supply,multi-level power protection,power status monitoring,self-diagnosis and fault alarm,used as KEBA Kemro K2 series power supply module spare replacement.

Product Brief

RS-091/A is KEBA old industrial rack power supply module for injection molding and die-casting machine automation equipment.Confirm compatibility with Kemro K2 backplane system before ordering.ESD protection required during handling and installation.
