Indramat R911190005 DC Bus Regenerative Supply Unit

Module Feature

R911190005 is the official Bosch Rexroth Indramat part number for model HVR03.2-W045N, belonging to the HVR regulated regenerative power supply family for the DIAX04 servo platform. It converts three-phase mains voltage into a stable 750V shared DC bus and feeds braking energy back to the grid. Nominal power rating is 45kW, continuous DC output 30kW, peak power 135kW for 0.3 seconds, with an integrated bleeder circuit rated for 80kW peak absorption. It uses built-in blower forced air cooling with IP10 open frame construction and supplies DC power to multiple HDS / HDD servo inverter modules in one drive group. Integrated protection functions cover overvoltage, undervoltage, overcurrent, overtemperature and mains fault monitoring. An RS232 service port supports commissioning and diagnostic access via IndraWorks software. Typical applications include CNC machine tools, metal forming presses, packaging machines and high dynamic multi-axis automation equipment.

Working principle

Three-phase AC power is rectified and regulated into constant 750V DC for connected servo inverters. When servo motors decelerate, regenerative energy is returned to the mains grid through the active IGBT circuit. When grid feedback capacity is exceeded, the internal bleeder resistor bank activates to consume excess energy and protect the DC bus. Internal sampling circuits continuously monitor bus voltage, output current and module temperature, exchanging status and alarm signals with the servo control system over the dedicated drive bus.

Onboard components

Active rectifier IGBT power assembly, DC bus capacitor bank, built-in cooling blower, bleeder resistor stack, voltage and current sampling board, internal drive communication interface, RS232 service connector, status indicator circuit, power terminal busbar.

LED indicators

Front panel LED indicators for power ready, run, fault and bleeder activation status; detailed fault codes and operating values are retrieved with IndraWorks software.

Hardware self‑diagnosis

Power-on self-test detects phase loss, DC bus over/under voltage, overcurrent, module overtemperature, blower failure, communication interruption and bleeder circuit faults. Fault events and history logs are stored inside the unit.

Programming software

Commissioning, parameter setup and troubleshooting use Rexroth IndraWorks software.

Electrical & Process Parameters

Model:R911190005 Brand:Bosch Rexroth Indramat Type Code:HVR03.2-W045N Device type:Regenerative DC Bus Power Supply Nominal power:45 kW Input:3AC 380~480V ±10%, 50/60Hz DC output:750 V DC Cooling:Internal blower air cooling Protection:IP10 Communication:Proprietary servo bus, RS232 service port Function:Regulated DC bus power and energy regeneration for multi-axis servo drives

Mechanical & Structure

Mounting:Cabinet backplane installation Protection class:IP10 Housing:Metal open frame with built-in blower

Environmental

Operating temperature:0℃ ~ +40℃ (derate above 40℃) Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing Certification:CE compliant Status:Indramat original DIAX04 servo spare module

Installation

Mount the module inside the control cabinet and maintain sufficient ventilation clearance. Connect three-phase mains input and DC bus output cables to servo inverters. Wire control power and communication lines. Complete topology verification and parameter upload in IndraWorks. Confirm regenerative feedback and bleeder threshold settings before machine commissioning.

Interface

Three-phase AC input terminal, DC bus +/- output terminal, RS232 service port, internal servo bus connector, 24V auxiliary control terminal, PE grounding terminal.

Diagnostic

DC bus overvoltage: Regenerative energy exceeds grid feedback capacity or bleeder circuit fault. Overtemperature fault: Blower damage, radiator clogging or insufficient cabinet airflow. No ready status: Mains phase missing, internal hardware fault or communication offline. Feedback unstable: Mains waveform distortion or impedance mismatch.

Product Brief

Indramat R911190005 regenerative power supply (HVR03.2-W045N), 45kW 380-480V, 750V regulated DC bus with grid regeneration, blower cooled, dedicated for Rexroth DIAX04 multi-axis servo drive systems.
