ICS TRIPLEX T8448 Zone Interface Module

Technical Specifications

Model:T8448

Brand:ICS TRIPLEX

Product type:TMR 40-channel zone interface module

System series:Trusted T8000 SIS

Bus type:Triple redundant parallel backplane bus

Compatible modules:T8300 / T8314 expander chassis,T8310 expander processor,T8311 expander interface

Redundancy:TMR triple modular redundant hot swap architecture

Field signal:24VDC,40 channels mixed digital input / output

Isolation:2500V channel to system galvanic isolation

Per channel protection:Built-in overcurrent protection

SOE resolution:1ms

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:0.60kg

Certification:CE,TÜV,SIL3

System compatibility

T8448 belongs to ICS TRIPLEX Trusted SIS safety instrumented system and installs inside T8300 or T8314 expander rack. It acts as zone interface between field safety devices and TMR controller,handles large quantity of 24V discrete DI/DO signals from safety switches,relay contacts and field actuators. Triplicated validated data is transmitted to expander processor. Widely deployed in oil & gas,petrochemical and chemical plants for ESD emergency shutdown and fire & gas safety protection.

Function

T8448 serves as high integrity 40-channel zone interface unit of Trusted TMR SIS. It processes mixed digital input and output signals and adopts TMR 2oo3 hardware voting logic to judge signal status. It supports 1ms high precision SOE sequence of events recording for incident trace analysis. Each channel continuously monitors open circuit,short circuit and overload faults. It supports hot swap replacement without shutting down the safety expansion rack.

Installation

Insert T8448 vertically into dedicated I/O slot of T8300/T8314 expander chassis. Wire field safety device cables to terminal assembly. Check channel status and SOE event logs via Trusted Workbench engineering software.

Interface

‑Gold finger connector for triple redundant backplane bus

‑Field termination interface for 40-channel 24V mixed DI/DO wiring

‑Front panel LED indicators for per-channel run,alarm and fault status

‑Onboard TMR signal processing,overcurrent protection and SOE timestamp circuit

Circuit feature

Conformal coated multi-layer PCB design,built-in surge and overvoltage protection circuit. Triple slice independent signal processing and hardware voting design,fully compliant with SIL3 functional safety hardware specifications.

Feature

T8448 is spare 40-channel zone interface board for ICS TRIPLEX Trusted SIS. Common faults include channel burnout,field wiring short circuit and backplane contact fault. Confirm field voltage and chassis compatibility before replacement.

Diagnostic

When channel open circuit,short circuit,overload or onboard hardware failure is detected,the module triggers fault alarm and uploads diagnostic messages and SOE event logs to safety workstation.

Built‑in function

Field mixed DI/DO signal processing,per-channel line fault monitoring,overcurrent protection and TMR signal voting for Trusted TMR expansion rack,used as SIS zone interface spare replacement.

Product Brief

T8448 is ICS TRIPLEX Trusted SIL3 TMR 40-channel 24VDC zone interface module,hot swappable for T8300/T8314 expander chassis,designed for large volume discrete safety signal interconnection. Verify system firmware compatibility before ordering. ESD anti-static protection must be followed during handling installation.
