HEIDENHAIN 617574-01 Encoder Signal Cable

Technical Specifications

Model： ID.Nr.617574-01

Brand： HEIDENHAIN

Product Type: Prefabricated multi-core shielded encoder signal cable assembly

Module Feature:

Function: HEIDENHAIN 617574-01 factory terminated shielded encoder cable. It delivers 5VDC supply power and transmits 1Vpp sine/cosine incremental or EnDat absolute position signals between HEIDENHAIN linear / rotary encoders and interpolation or servo control units. Full copper braid shielding suppresses electromagnetic interference to guarantee stable high-precision position transmission for feed axis, spindle and rotary table closed-loop control on heavy horizontal boring mills and multi-axis machining centers.

Cable type: Multi-core shielded PUR signal cable Matched Device: HEIDENHAIN ERN, ROQ, RON rotary encoders and LC, LIDA, LIP linear read heads with M23 interface Onboard components: Tinned copper conductors, PE insulation, full copper braid shielding, molded M23 connectors on both ends, strain relief protection

LED indicators: Not applicable (Cable assembly)

Hardware self-diagnosis: Continuity test, insulation resistance test, shield continuity inspection

Programming software: No programming software required

Electrical Parameters

Voltage rating: 300V

Mechanical & Structure:

Mounting: Routed inside machine cabinet and machine frame Outer jacket: Oil-resistant, coolant-resistant, flame-retardant PUR jacket Bending radius: ≥10 × cable outer diameter

Environmental:

Operating temperature: -20℃ ~ +80℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: HEIDENHAIN standard pre-assembled encoder signal cable

System compatibility

Compatibility description: 617574-01 belongs to HEIDENHAIN encoder accessory family. Compatible with HEIDENHAIN incremental 1Vpp and EnDat absolute encoders equipped with M23 connector interface. Suitable for Fives Giddings & Lewis PIC900 CNC heavy boring mill system.

Function

Function description: 617574-01 is prefabricated shielded encoder cable manufactured by HEIDENHAIN. It connects linear scale scanning head or rotary encoder to interpolation unit or servo drive, transferring DC power and position feedback signals. Copper braid shielding protects weak measuring signals from electromagnetic noise generated by high-power servo motors. PUR outer jacket resists cutting fluid, oil mist and metal chips in machine workshop environment. It is encoder feedback wiring spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off encoder and CNC controller 5VDC power. Disconnect old cable connectors at encoder and electronics end. Route 617574-01 separately from high-current servo power cables. Secure cable clamps and connectors. Check insulation resistance and shield grounding. Restore power, verify encoder communication and axis position stability.

Interface

Interface list: M23 flange connectors on both ends, 5VDC power and signal terminals for HEIDENHAIN 617574-01.

Diagnostic

Troubleshooting: No encoder signal: Check 5VDC supply, internal wire breakage or connector pin damage. Intermittent position fault: Poor shield grounding, connector corrosion or cable insulation aging. Signal amplitude drop: Excessive bending damage to internal conductors or shield fracture.

Product Brief

Brief description: 617574-01 is HEIDENHAIN shielded prefabricated encoder signal cable assembly,for transmitting power and position feedback signals between HEIDENHAIN encoders and CNC electronics on heavy CNC boring mills,encoder wiring spare.
