GE Fanuc IC695310-GW Gateway Module

Technical SpecificationsModel：IC695310-GW Brand：GE Fanuc Product Type: Single-slot plug-in industrial network gateway module for PACSystems RX3i universal backplane

Module Feature:Function: Industrial protocol gateway module for RX3i PACSystems, performs bidirectional protocol conversion and data forwarding between different industrial networks. Network ports: Multiple configurable Ethernet and serial interfaces Supported protocols: Modbus TCP, Modbus RTU, EGD, DNP3, IEC 60870-5-104, custom protocol mapping Data mapping: Tag-based bidirectional data mapping, support data filtering and scaling LED indicators:OK, LINK, ACT, FAULT diagnostic lights Hardware self-diagnosis:Port status detection, protocol connection monitoring, backplane bus monitoring Programming software:Proficy Machine Edition, gateway configuration tool

Electrical ParametersBackplane supply:+5V and +3.3V from RX3i backplane Power consumption:Max 4.2W No external field power required

Mechanical & Structure:Mounting:Plug into RX3i universal backplane single slot Weight:0.24kg Protection class:IP20

Environmental:Operating temperature:0℃ ~ +60℃ Ambient humidity:5~95% non-condensing Certification:UL, CE Status:Manufacturer discontinued legacy spare part

System compatibilityIC695310-GW belongs to GE Fanuc PACSystems RX3i I/O family. Compatible with RX3i CPU, power supply and other RX3i I/O modules. Widely used for interconnection of heterogeneous control networks in power, water treatment and chemical process systems.

FunctionIC695310-GW is a high-performance protocol gateway module for RX3i PACSystems. It realizes seamless data exchange between different industrial communication protocols without occupying CPU resources. Tag mapping function supports data scaling and filtering, convenient for connecting third-party controllers, meters and remote SCADA systems. Built-in port and link diagnostics simplify network troubleshooting.

InstallationFollow lockout/tagout safety procedure before installation. Cut off rack backplane power. Insert IC695310-GW into RX3i backplane slot and lock retainer. Connect Ethernet or serial field cables. Configure protocol, IP address and tag mapping in gateway configuration software. Power on and verify cross-protocol data transmission.

InterfaceRX3i backplane gold-edge connector,multi RJ45 Ethernet ports,serial terminal interface,on-board OK / LINK / ACT / FAULT LED indicators for GE Fanuc IC695310-GW.

DiagnosticNo cross-network data exchange:Check port wiring,IP setting and protocol parameter matching. FAULT alarm:Backplane communication failure or gateway configuration error. LINK light off:Ethernet cable fault or remote device offline.

Product BriefIC695310-GW is GE Fanuc legacy PACSystems RX3i industrial protocol gateway module,for bidirectional data conversion and interconnection between different industrial control networks,discontinued industrial communication spare card.
