Fisher 41B8558X012 Valve Trim Spare Component

Technical Specifications

Model：41B8558X012 Brand：Fisher Product Type: Control valve internal trim spare component

Module Feature

Fisher 41B8558X012 is precision alloy spare component for Fisher globe control valve trim assembly. It cooperates with valve plug and cage to form complete throttling trim. It features high mechanical strength,anti-corrosion and anti-erosion performance. Widely applied in oil,gas,chemical and power plant process control valves.

Working principle: Valve trim positioning and auxiliary throttling Onboard components: Alloy mechanical component, fixing pins, sealing washer

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, dimensional check, surface wear inspection, assembly fit test

Programming software

No dedicated software required

Mechanical & Structure

Mounting: Installed inside globe control valve body Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +425℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher valve trim spare part

System compatibility

Compatible with matched Fisher globe control valve trim set and pneumatic diaphragm actuator for industrial process control system.

Function

41B8558X012 is valve trim spare component manufactured by Fisher. It fixes and positions internal trim parts, maintains coaxiality of plug and cage during valve movement. It reduces mechanical friction and vibration during fluid throttling. It ensures valve flow characteristic and seat tightness. It is essential spare part for control valve trim overhaul.

Installation

Follow lockout/tagout safety procedure before installation. Isolate pipeline and release process pressure. Disassemble valve bonnet, replace old 41B8558X012 component. Check assembly coaxiality and sliding clearance. Reassemble valve and perform hydrostatic test and seat leakage inspection.

Interface

Valve body internal mounting structure, fixed locating pins, no LED indicators on 41B8558X012.

Diagnostic

Valve internal leakage: Trim misalignment caused by worn component. Abnormal vibration noise: Trim assembly loose or component deformation. Valve sticking: Mechanical friction increase from worn spare part.

Product Brief

41B8558X012 Fisher globe control valve trim spare component,matched with Fisher globe valve trim and pneumatic actuator,used for industrial process control valve overhaul maintenance,valve internal trim spare part.
