Extreme Networks X440-G2-24x-10GE4 Fiber Campus Edge Switch

Technical Specifications

Model：X440-G2-24x-10GE4 Brand：Extreme Networks Product Type: 1U rack mount Layer2/L3 stackable gigabit fiber access switch

Front Ports:

• 24 × 1GBASE-X SFP fiber slots for gigabit fiber connections

• 4 × unpopulated 10/100/1000BASE-T RJ45 copper combo ports

• 1 × USB 2.0 port

• 1 × RJ45 serial console port

• LED indicators for port link, activity, power and system health

Rear Panel Interfaces:

• 4 × SFP+ slots, base speed 1G, upgradeable to 10G via software license

• 1 × OOB 10/100/1000BASE-T management port

• RPS redundant power supply backup interface

• Built-in fixed AC power supply

Switching & Layer Features: Switch Fabric: 128 Gbps full duplex Forwarding Rate: 95.2 Mpps MAC Address Table: 128K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN Routing: IPv4 / IPv6 static & dynamic routing Security: 802.1X, MAC authentication, storm control, bidirectional ACL QoS: Hardware L2-L4 classification, 8 priority queues Stacking: SummitStack-V, up to 8 switches stacked, SFP+ ports can serve as stack ports Management: ExtremeXOS OS, SNMP, SSH, Web GUI, Extreme Management Center

Power & Mechanical: Power Supply: Built-in fixed AC 100-240V power supply Cooling: Internal fixed fan, front-to-back airflow Operating temperature：0℃ ~ +50℃ Dimension: 442mm × 44mm × 300mm Weight: Approx 4.6 kg Mounting: Standard 19-inch 1U rack bracket Software OS: ExtremeXOS

System compatibility

X440-G2-24x-10GE4 belongs to Extreme X440-G2 series fiber edge switch family. Compatible with Extreme certified SFP and SFP+ transceivers. Supports SummitStack-V stacking with other X440-G2 switches. Designed for enterprise campus long-distance fiber access, factory automation and data center access layer. Widely used for fiber LAN upgrade and spare replacement.

Function

X440-G2-24x-10GE4 is 1U stackable gigabit fiber edge switch manufactured by Extreme Networks. It provides 24×1G SFP fiber ports for remote terminal access, 4 combo RJ45 copper ports, rear 4 SFP+ slots which can be activated to 10G high-speed uplink after license purchase. SummitStack-V technology combines multiple physical switches into one logical unit for simplified centralized management. Supports full IPv4/IPv6 routing, 802.1X authentication, VLAN segmentation and hardware QoS. Built-in power supply reduces deployment complexity. Widely deployed for campus, factory and industrial building fiber access network spare replacement.

Installation

Follow ESD protection procedure. Mount switch to standard 19-inch 1U rack. Connect AC power cord. Insert SFP / SFP+ transceivers for fiber connections. Access serial console port for initial ExtremeXOS configuration, set VLAN, stacking, routing and QoS policy. Purchase and activate 10G license if 10G uplink required. Verify port connectivity and stack status after power-up.

Interface

24×1G SFP fiber ports,4×RJ45 combo copper ports,4 rear SFP+ slots,USB port,serial console port,OOB management port,RPS backup power interface,built-in AC PSU,LED indicators for Extreme Networks X440-G2-24x-10GE4.

Feature

Original Extreme Networks X440-G2-24x-10GE4 fiber campus edge switch,1U,24×1G SFP +4 combo RJ45 +4 license-upgradable 10G SFP+,SummitStack-V stacking,ExtremeXOS OS,fixed internal power. This spare unit is used for enterprise fiber access network maintenance and hardware replacement.

Diagnostic

Switch boot failure: Check AC power input and power cord connection. Fiber port link down: Confirm SFP transceiver compatibility, inspect fiber end face and cable quality. 10G port inactive: Verify 10G license activation status. Stack split fault: Check stacking SFP+ cable, match ExtremeXOS firmware version. Overheat alarm: Check internal fan working condition and rack ventilation.

Product BriefX440-G2-24x-10GE4 is Extreme Networks X440-G2 series 1U stackable fiber access switch with 24 SFP gigabit ports and license-enabled 10G SFP+ uplink, ExtremeXOS OS,classic spare for long-distance campus fiber edge network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
