Extreme Networks X440-G2-24t-GE4 Gigabit Edge Access Switch

Technical SpecificationsModel：X440-G2-24t-GE4 Brand：Extreme Networks Product Type: 1U rack mount enterprise Gigabit non-PoE access switch, X440-G2 generation

Front Ports:

• 24 × 10/100/1000BASE-T RJ45 copper ports, auto-negotiation

• 4 × 1G SFP slots for 1000BASE-X fiber transceivers

• 1 × RJ45 serial console port

• 1 × USB 2.0 port (available on EXOS 22.2 and newer)

• LED indicators for port link, activity and system health

Rear Panel Interfaces:

• 1 × OOB 10/100/1000BASE-T management port

• Redundant power supply connector

• AC power inlet

Switching & Layer Features: Switch Fabric: 128 Gbps Forwarding Rate: 95 Mpps MAC Address Table: 16K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN, private VLAN Routing: IPv4 / IPv6 static routing Security: 802.1X, MAC authentication, storm control, ACL, DoS protection QoS: Hardware L2-L4 classification, 8 priority queues per port Management: SNMP, SSH, Web GUI, ExtremeXOS CLI, ExtremeCloud IQ, Extreme Management Center Note: This X440-G2-24t-GE4 variant does not support stacking

Power & Mechanical: Power Supply: Built-in universal AC 100-240V 50/60Hz Cooling: Built-in fan cooling Operating temperature：0℃ ~ +60℃ (wide temperature range) Dimension: 440mm × 44mm × 320mm Weight: Approx 3.7 kg Mounting: Standard 19-inch 1U rack bracket Software OS: ExtremeXOS

System compatibility

X440-G2-24t-GE4 belongs to X440-G2 edge switch family, non-PoE, non-stackable version. Compatible with standard 1G SFP optical transceivers. Supports external redundant power supply. Wide operating temperature design, suitable for factory, harsh environment and enterprise campus wiring closet maintenance replacement.

Function

X440-G2-24t-GE4 is 1U gigabit non-PoE access switch for enterprise and industrial edge. 24×1G copper ports connect desktop PCs, printers and non-powered network terminals. Four dedicated 1G SFP slots provide fiber uplink to aggregation/core switch. Supports IPv4/IPv6 routing, 802.1X access authentication, VLAN segmentation and hardware QoS for voice/video traffic. Wide temperature capability makes it fit for non-air-conditioned equipment rooms. External redundant power connector improves network reliability. Widely deployed for factory workshop, school and office gigabit wired access spare replacement.

InstallationFollow ESD protection procedure. Mount switch to standard 19-inch 1U rack. Connect AC power cord. Install external redundant PSU if required. Insert 1G SFP transceivers for fiber uplink. Access serial console port for initial ExtremeXOS configuration, set VLAN, ACL and QoS policy. Verify port connectivity after power-up.

Interface24×1G RJ45 ports,4×1G SFP slots,serial console port,USB port,OOB management port,AC power inlet,redundant power connector,LED indicators for Extreme Networks X440-G2-24t-GE4.

FeatureOriginal Extreme Networks X440-G2-24t-GE4 gigabit non-PoE edge switch,24×1G copper +4×1G SFP uplink,wide temperature 0~60℃,ExtremeXOS OS,support external redundant power. This spare switch is used for enterprise and industrial wired access network maintenance and hardware replacement.

DiagnosticSwitch boot failure: Check AC power input and cable, verify external redundant power wiring if used. SFP port link down: Confirm SFP transceiver compatibility, inspect fiber end face and cable quality. USB port inactive: Upgrade ExtremeXOS firmware to version 22.2 or higher. High temperature alarm: Check fan operation and rack ventilation.

Product BriefX440-G2-24t-GE4 is Extreme X440-G2 series 1U 24-port gigabit non-PoE access switch with four 1G SFP uplink ports and wide temperature rating,classic spare for industrial and enterprise wiring closet network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
