Extreme Networks VIM1-10G8X Versatile Interface Module

Technical SpecificationsModel：VIM1-10G8X Brand：Extreme Networks Product Type: Versatile Interface Module (VIM), expansion mezzanine card for Summit X650 series switches

Front Ports:

• 8 × SFP+ slots for 10GBASE-R fiber transceivers, DAC/AOC cables

• 2 × dedicated 40G SummitStack stacking ports

• LED indicators for port link, activity and module fault

Switching & Layer Features: Max Jumbo Frame: 9216 bytes (depends on host switch configuration) Supported Functions: 10G uplink, SummitStack-V stacking, L2/L3 forwarding, VLAN tagging, hardware QoS QoS: Hardware L2-L4 classification, 8 priority queues per port Stacking: SummitStack-V, long-distance stacking up to 40km over fiber

Power & Mechanical: Power Supply: Powered by host switch backplane Weight: Approx 0.91 kg Dimension: 13.2mm × 4.3mm × 25.2mm Operating temperature：0℃ ~ +40℃ Installation: Non hot-swappable; power down switch before module insertion Software OS: ExtremeXOS

System compatibility

VIM1-10G8X belongs to VIM1 family, designed exclusively for Summit X650 series switches. Compatible with 10G SFP+ optical transceivers, direct attach copper and active optical cables. The dedicated SummitStack ports build high-speed stack group for multiple X650 units.

Function

VIM1-10G8X is optional versatile interface module for Summit X650 switches. It provides 8×10G SFP+ uplink ports to connect to core or aggregation layer, plus two independent 40G SummitStack ports for switch stacking. The stacking ports are separated from data ports and do not consume 10G uplink resources. It supports long-distance SummitStack-V stacking up to 40km, ideal for distributed campus networks. Module delivers wire-speed 10G forwarding, supports VLAN segmentation and QoS traffic scheduling. Widely deployed for enterprise campus and data center top-of-rack network expansion.

InstallationFollow ESD protection procedure. Power off the Summit X650 switch. Remove blank panel from VIM slot, insert VIM1-10G8X and secure screws. Install SFP+ transceivers and cables. Power on switch, verify module detection via ExtremeXOS CLI. Configure uplink and stacking parameters, check port connectivity.

Interface8×10G SFP+ slots,2×40G SummitStack stacking ports,port status LED,fault LED,backplane connector for Extreme Networks VIM1-10G8X.

FeatureOriginal Extreme Networks VIM1-10G8X VIM expansion card,8×10G SFP+ uplink + dedicated 40G SummitStack ports,for Summit X650 series,ExtremeXOS supported,long-distance stacking capability. This spare module is used for Summit X650 switch high-speed uplink and stacking expansion.

DiagnosticModule undetected: Power down, re-seat module, verify ExtremeXOS firmware compatibility. 10G port link down: Confirm SFP+ transceiver compatibility, inspect cable quality and port configuration. Stacking negotiation fail: Check stacking cable, match ExtremeXOS firmware on all stack members.

Product BriefVIM1-10G8X is Extreme VIM1 versatile interface module with 8×10G SFP+ plus 40G SummitStack ports,classic spare for Summit X650 series switch uplink and stacking upgrade.
