Extreme Networks VIM-4X10GE 4 Port 10G SFP+ VIM Uplink Module

Technical Specifications

Model：VIM-4X10GE Brand：Extreme Networks Product Type: Hot-swappable versatile uplink expansion interface module (VIM)

Front Ports:

• 4 × 1G /10G SFP+ slots, compatible with SFP+ optical transceivers and DAC copper cables

• Port LED indicators for link status, activity and fault alarm

Interface & Mechanical:

• Designed to install into dedicated VIM slot of compatible Summit switches

• Hot swap support, replace module without powering off host switch

• Onboard hardware forwarding circuit, connected via internal backplane connector

Switching & Layer Features: Bandwidth: 40Gbps full duplex total for module MAC Address Table: Shared with host switch Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN Routing: Inherit IPv4 / IPv6 routing function from host ExtremeXOS Security: 802.1X, ACL, storm control, MACsec (variant dependent) QoS: Hardware L2-L4 classification, 8 priority queues Management: Controlled by host switch, ExtremeXOS OS

Power & Environmental: Power Supply: Powered by host switch backplane Cooling: Shared airflow from host switch fan tray Operating temperature：0℃ ~ +50℃ Form factor: Small form VIM plug-in module Weight: Approx 0.35 kg

System compatibility

VIM-4X10GE belongs to Extreme VIM versatile interface accessory family. Compatible with X460-G2, X465, V400 series switches equipped with VIM slot. Supports stacking and Fabric Connect functions on matched host hardware. Widely used to add high-speed 10G uplink ports for enterprise aggregation and edge switch spare replacement.

Function

VIM-4X10GE is pluggable high-speed uplink expansion module manufactured by Extreme Networks. It adds four 10G SFP+ ports to the host switch for fiber uplink, inter-switch stacking or server connection. Hot swap design allows online replacement without network shutdown. All switching, routing and security functions are managed via the main switch ExtremeXOS system. It provides flexible port expansion options when upgrading network bandwidth. Widely deployed for campus, factory and data center edge network spare replacement.

Installation

Follow ESD protection procedure. Remove blank cover plate of switch VIM slot. Insert VIM-4X10GE module fully and tighten fixing screws. Insert SFP+ transceiver or DAC cable. Power on and verify module detection on ExtremeXOS console, configure port VLAN, routing and QoS parameters. Check port link status after configuration.

Interface

4×10G SFP+ ports,internal backplane connector,port LED indicators for Extreme Networks VIM-4X10GE.

Feature

Original Extreme Networks VIM-4X10GE versatile uplink module,4×10G SFP+ ports,hot swappable,ExtremeXOS managed,expand high-speed uplink for compatible summit switches. This spare unit is used for enterprise switch uplink expansion and hardware maintenance replacement.

Diagnostic

Module undetected: Confirm module fully seated, screws locked and VIM slot enabled. Port link down: Check SFP+ / DAC compatibility, fiber cleanliness and optical power. Port error counter rising: Inspect cable quality, fiber end face or transceiver fault. Temperature warning: Verify host switch fan operation and rack ventilation.

Product BriefVIM-4X10GE is Extreme Networks hot-swappable VIM uplink module with 4×10G SFP+ ports for Summit series switches, used to expand high-speed fiber uplink ports,classic spare for enterprise edge and aggregation network upgrade.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
