Extreme Networks V300HT-8P-2X Hardened PoE Virtual Port Extender

Technical Specifications

Model：V300HT-8P-2X Brand：Extreme Networks Product Type: Compact industrial hardened PoE+ virtual port extender

Front Ports:

• 8 × 10/100/1000BASE-T RJ45 PoE+ ports, IEEE802.3at, max 30W per port

• 2 × 1/10G SFP+ uplink slots, support 1G or 10G optical transceivers

• 1 × USB 2.0 port

• 1 × RJ45 serial console port

• LED indicators for port link, activity and system health

Rear Panel Interfaces:

• DC power input terminal block

• Ground terminal

• Wall / DIN rail mounting brackets support

Switching & Layer Features: Switch Fabric: 28 Gbps Forwarding Rate: 20.8 Mpps MAC Address Table: 16K entries Max Jumbo Frame: 9216 bytes Function: Virtual Port Extender, managed by ExtremeXOS core switch Security: 802.1X, MAC authentication, storm control, ACL QoS: Hardware L2-L4 classification, 8 priority queues per port Stacking: Not standalone stacking, works with compatible Extreme core switches Management: Managed via parent ExtremeXOS switch, local console for basic diagnostics

Power & Mechanical: Power Supply: DC power input, dedicated HT power module; total PoE budget 240W Cooling: Fanless passive cooling Operating temperature：-40℃ ~ +70℃Dimension: 145mm × 44mm × 115mm Weight: Approx 0.85 kg Mounting: DIN rail, wall mount, rack mount optional Software OS: Controlled by ExtremeXOS on parent core switch

System compatibility

V300HT-8P-2X belongs to V300 series hardened virtual port extender. It is not an independent standalone switch, requires compatible Extreme core switch to operate. Compatible with standard 1G /10G SFP+ transceivers. Fanless wide temperature design for harsh industrial environments. Widely used for factory automation, outdoor cabinet, non-air-conditioned equipment room network expansion and spare replacement.

Function

V300HT-8P-2X is fanless industrial hardened PoE+ virtual port extender. 8 PoE+ copper ports supply power and data to IP cameras, wireless access points and industrial PoE terminals. Two SFP+ uplink ports support 1G or 10G fiber connection to main core switch. All control functions are offloaded to the parent ExtremeXOS core switch, simplifies network management. Supports 802.1X authentication, VLAN segmentation and hardware QoS. Fanless design eliminates fan failure risk, wide temperature range adapts to harsh industrial sites. Widely deployed for factory workshop, outdoor equipment cabinet and industrial edge PoE network expansion spare replacement.

Installation

Follow ESD protection procedure. Mount unit on DIN rail or equipment wall. Connect DC power supply. Insert SFP/SFP+ transceiver for fiber uplink and connect fiber cable to core switch. Access serial console port for basic diagnostic. Complete port configuration on parent ExtremeXOS core switch. Verify port connectivity and PoE output after power-up.

Interface

8×PoE+ RJ45 ports,2×SFP+ uplink slots,USB port,serial console port,DC power terminal,ground terminal,LED indicators for Extreme Networks V300HT-8P-2X.

Feature

Original Extreme Networks V300HT-8P-2X hardened industrial PoE+ port extender,8×30W PoE+ ports +2×1/10G SFP+,fanless,-40~+70°C wide temperature,managed by ExtremeXOS core switch. This spare unit is used for industrial edge PoE network expansion and hardware replacement.

Diagnostic

Unit offline: Check DC power wiring and power module output, verify uplink SFP+ transceiver and fiber link, confirm parent core switch configuration. PoE port no power: Check PoE budget allocation on core switch, verify cable and PoE powered device compatibility. SFP+ link down: Confirm SFP+ module compatibility, inspect fiber end face and cable quality. High temperature warning: Check cabinet ventilation, ensure no direct heat radiation.

Product BriefV300HT-8P-2X is Extreme V300 series fanless hardened industrial virtual port extender with 8-port PoE+ and dual 1/10G SFP+ uplink, supporting -40 to +70°C wide temperature,classic spare for harsh environment edge PoE network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
