Extreme Networks Summit X480-48T Gigabit Combo Managed Switch

Technical SpecificationsModel:X480-48T Brand:Extreme Networks Product Type:1U rackmount stackable Layer2/Layer3 managed switch (non-PoE) Ports:

• 48 ×10/100/1000BASE-T RJ45 copper ports

• 4 × shared 1000BASE-X SFP combo ports (shared with last 4 RJ45 ports) Rear expansion slot:VIM2 slot, supports VIM2-10G4X (4×10G XFP) or VIM2-SummitStack stacking module Switching capacity:184 Gbps Forwarding rate:136.9 Mpps MAC address table:64000 entries Jumbo frame:9216 bytes Stacking:SummitStack128 / SummitStack-V80, up to 8 units stacked OS:ExtremeXOS, minimum version 12.4.1 Management interfaces:RJ45 serial console port,10/100 out-of-band management port Power & fan:Hot-swappable redundant PSU slots,hot-swappable fan tray,front-to-back airflow Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:6.3kg

System compatibilityX480-48T belongs to Extreme Networks Summit X480 high-performance enterprise access family. Compatible with Extreme validated 1G SFP transceivers SX/LX and VIM2 series rear modules. It can stack with X460,X480 series switches. Widely used for enterprise campus wiring closet mixed copper/fiber access spare replacement.

FunctionX480-48T is stackable multi-layer gigabit access switch without PoE. It provides 48 copper gigabit ports for end-user access; the last four ports can switch to SFP fiber mode for fiber uplink. It supports wire-speed Layer2 switching,Layer3 routing,VLAN segmentation,STP/RSTP/MSTP,LACP link aggregation,ACL,QoS and multicast control. It monitors SFP DDM optical diagnostics,port link state,system temperature,power and fan health, and sends hardware fault alarms. Used for large enterprise campus and building aggregation networks.

InstallationMount the switch on standard 19-inch 1U rack. Install hot-swappable PSU and fan tray. Insert SFP transceivers and fiber cables if combo fiber mode is used. Install VIM2 uplink/stacking module as required. Connect console port for ExtremeXOS configuration. Verify boot,port link and stacking function before commissioning.

Interface48×1G RJ45 ports,4×shared SFP combo slots,RJ45 serial console,out-of-band management port,status LEDs,reset button,rear VIM2 expansion slot,dual PSU slots,fan tray,ground terminal,rack mounting ears for Extreme Networks Summit X480-48T.

FeatureOriginal Extreme Networks Summit X480 1U rackmount Layer3 stackable gigabit combo switch,48 copper ports plus 4 shared SFP fiber combo ports,flexible VIM2 rear expansion for 10G uplink or high-speed stacking,hot-swappable redundant power and fans,DDM optical monitoring,ExtremeXOS operating system,built-in self-diagnostic function. This spare supports legacy enterprise campus high-density mixed copper/fiber access deployment.

DiagnosticSwitch fails to boot: check AC power input and PSU module health. Copper port link down: inspect Cat5e/Cat6 cable quality and auto-negotiation. Combo port fiber no link: verify SFP module, fiber cable and combo mode configuration. SFP module undetected: confirm Extreme validated SFP and proper insertion. VIM2 module not detected: verify VIM2-only compatibility and ExtremeXOS firmware version. Over-temperature alarm: check fan tray operation and rack airflow,remove dust buildup. Stacking failure: verify matching ExtremeXOS firmware and stacking cable integrity.

Product BriefX480-48T is Extreme Networks Summit X480 1U rackmount Layer3 stackable managed gigabit combo switch with 48×1G RJ45 and 4 shared SFP combo ports plus VIM2 rear expansion slot,classic spare part for enterprise campus mixed copper/fiber access network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
