Extreme Networks Summit X450e-48p Gigabit PoE Edge Access Switch

Technical Specifications

Model：Summit X450e-48p Brand：Extreme Networks Product Type: 1U rack mount stackable enterprise Gigabit PoE Layer3 access switch

Front Ports:

• 48 × 10/100/1000BASE-T RJ45 PoE ports, IEEE802.3af, max 15.4W per port

• 4 × combo gigabit ports (ports 45-48 shared PHY): either 10/100/1000BASE-T RJ45 or 1G SFP fiber

• 1 × RJ45 serial console port

• LED indicators for port link, activity, stack ID and system health

Rear Panel Interfaces:

• 1 × OOB 10/100BASE-T management port

• Expansion slot for XGM2 series dual 10G uplink card

• Dedicated SummitStack stacking ports

• AC power inlet

• External PoE power connector, compatible with EPS-C / EPS-600LS external power system

Switching & Layer Features: Switch Fabric: 256 Gbps Forwarding Rate: 130.9 Mpps MAC Address Table: 16K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN Routing: IPv4 / IPv6 static routing Security: 802.1X, MAC filtering, storm control, centralized ACL, DoS protection QoS: Hardware L2-L4 classification, 8 priority queues per port Stacking: SummitStack, combine multiple X450e switches as single logical unit Management: SNMP, SSH, Web GUI, ExtremeXOS CLI

Power & Mechanical: Power Supply: Built-in universal AC 100-240V 50/60Hz; internal PSU delivers 370W PoE budget. Full 15.4W on all 48 PoE ports requires EPS-C or EPS-600LS external power module, total PoE budget up to 740W Cooling: Built-in cooling fan Operating temperature：0℃ ~ +40℃ Dimension: 441mm × 44mm × 432mm Weight: Approx 7.2 kg Mounting: Standard 19-inch 1U rack bracket Software OS: ExtremeXOS, max supported EXOS version 15.3.x

System compatibility

Summit X450e-48p belongs to X450e gigabit edge switch family, 48-port PoE Layer3 model. Compatible with 1G SFP transceivers and XGM2 10G expansion card. Can stack with other X450e series switches. Supports EPS-C / EPS-600LS external PoE power supply. End-of-sale hardware platform, commonly used for legacy enterprise campus PoE network overhaul and spare replacement.

Function

Summit X450e-48p is 1U stackable Layer3 Gigabit PoE access switch for enterprise campus deployment. 48 PoE ports transmit data and supply power to wireless APs, IP phones and network cameras. Four combo ports provide flexible uplink via copper or fiber medium. Rear expansion slot accepts XGM2 dual 10G card for high-speed connection to aggregation or core switch layer. SummitStack technology unifies multiple stacked switches under single management. Supports IPv4/IPv6 static routing, 802.1X authentication, VLAN segmentation and hardware QoS to prioritize voice and video traffic. External EPS-C / EPS-600LS power module unlocks full PoE power budget for all ports, improving system reliability. Widely applied in office, school and hospital legacy PoE wiring closet spare replacement.

Installation

Follow ESD protection procedure. Mount switch to standard 19-inch 1U rack. Connect AC power cord. Install EPS-C or EPS-600LS external PoE PSU if full PoE capacity required. Insert SFP transceiver for fiber uplink or install XGM2 10G option card for high-speed uplink. Deploy SummitStack cable for multi-unit stacking. Access serial console port for initial ExtremeXOS configuration, set VLAN, ACL and QoS policy. Verify stack synchronization and port connectivity after power-up.

Interface

48×1G PoE RJ45 ports,4×gigabit combo ports,serial console port,OOB management port,XGM2 10G expansion slot,SummitStack stacking ports,AC power inlet,external PoE power connector,LED indicators for Extreme Networks Summit X450e-48p.

Feature

Original Extreme Networks Summit X450e-48p legacy L3 PoE edge switch,48×1G PoE +4 gigabit combo uplink,optional XGM2 10G uplink,SummitStack stacking,ExtremeXOS OS,support EPS-C / EPS-600LS external PoE power. This spare switch is used for enterprise PoE wired access network maintenance and hardware replacement.

Diagnostic

Switch boot failure: Check AC power input and cable, verify EPS-C / EPS-600LS power wiring if used. PoE port no power: Confirm external PoE power module installation, check PoE budget allocation, inspect cable and powered device compatibility. Combo port link down: Confirm SFP transceiver compatibility, check fiber end face and cable quality. 10G expansion card undetected: Power down the unit and re-seat XGM2 card, verify firmware compatibility. Stack split: Inspect stacking cable, match ExtremeXOS firmware version across stack members.

Product BriefSummit X450e-48p is Extreme X450e series 1U 48-port gigabit stackable Layer3 PoE access switch with combo uplink and optional 10G expansion slot,classic spare for legacy enterprise high-density PoE wiring closet network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
