Extreme Networks A4H124-24P Fast Ethernet PoE Stackable Switch

Technical SpecificationsModel:A4H124-24P Brand:Extreme Networks Product Type:1U rackmount stackable Layer2/Layer3 PoE access switch Ports:24 × 10/100BASE-T RJ45 PoE ports,2 × 10/100/1000BASE-T stacking/uplink RJ45 ports,2 × SFP 1000BASE-X gigabit uplink slots PoE standard:IEEE 802.3af PoE, max 15.4W per port Switching capacity:12.8 Gbps Forwarding rate:9.5 Mpps MAC address table:16000 entries VLAN:4094 VLAN IDs Redundancy:Supports external RPS redundant power supply Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:2.58 kg

System compatibilityA4H124-24P belongs to Extreme Networks A4 stackable switch family, formerly Enterasys. Multiple A4 units can be stacked together. Compatible with Extreme validated 1G SFP transceivers and fiber patch cords. Widely used for legacy enterprise campus access, IP phone and wireless AP deployments.

FunctionA4H124-24P is a managed fast ethernet PoE stackable access switch. It supports static routing, VLAN segmentation, STP/RSTP/MSTP, LACP, ACL, QoS, IGMP snooping and SNMP monitoring. It supplies power to IP phones and wireless access points. It monitors port link status, PD power consumption, chassis temperature and power supply health. Used to build stacked resilient fast ethernet access networks.

InstallationMount the switch on 19-inch 1U rack. Connect AC power cord; external RPS can be installed optionally. Insert SFP transceivers and fiber cables for gigabit uplink. Connect Cat5e cables to PoE RJ45 access ports. Connect DB9 serial console port for EOS configuration. Verify boot sequence, port link and PoE status before putting into production.

Interface24×PoE RJ45 fast ethernet ports,2×RJ45 stacking ports,2×SFP gigabit uplink slots,DB9 serial console port,status LEDs,AC power inlet,RPS connector,rack mounting ears for Extreme Networks A4H124-24P.

FeatureOriginal Extreme Networks A4 series 1U rackmount 24-port 100BASE-T PoE stackable Layer3 switch, transceiver DDM monitoring, external redundant power support,EOS operating system,built-in self-diagnostic function. This spare supports legacy enterprise voice and wireless access deployment for campus wiring closets.

DiagnosticSwitch fails to boot: check AC power cord and wall power supply. PoE port no power: verify PD detection, total PoE budget and port enable status. Port link down: check Cat5e cable, SFP transceiver and port admin status. SFP uplink failure: check SFP module and fiber type matching. Stacking failure: verify same firmware version among stacked A4 switches. Over-temperature alarm: inspect chassis ventilation and clear dust.

Product BriefA4H124-24P is Extreme Networks 1U rackmount 24-port 100BASE-T PoE stackable Layer3 managed switch with 2×RJ45 stacking and 2×SFP gigabit uplink slots, classic spare part for legacy enterprise wiring closet access network overhaul.
